A335 P11 P22 Sch80 9-180 ° alloy seamless steel elbow pipe fittings quality assurance


Manganese steel alloy elbow is usually used in concrete transmission pipeline, slurry transmission pipeline and other pipelines with serious wear consumption due to its excellent performance of withstanding impact, extrusion and material wear. The high manganese steel alloy elbow is used in the pipeline with intense fluid flow and strong impact; Alloy elbow made of nickel steel is usually used in normal temperature transmission pipeline with high concentration of oxidizing acid (nitric acid, sulfuric acid), but it will be seriously corroded in transmission pipeline with reducing acid (hydrochloric acid, dilute sulfuric acid, etc.), unless the concentration of hydrochloric acid is very low; Martensitic alloy elbow has high high temperature strength, oxidation resistance and water vapor corrosion resistance below 650 ℃, but poor weldability. Therefore, it is often used in high-temperature steam transmission pipeline and water gas pipeline. Executive standards: GB/T12459-2005, GB/T13401, GB/T10752-1999.



SIZE

ASTM B366 WPNCMC Seamless Butt Weld Fittings: 1/2" - 10"
ASTM B366 GRADE WPNCMC Welded Butt Weld Fittings: 1/2" - 48"

DIMENSIONS ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
THICKNESS SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
TYPES

ASTM B366 GRADE WPNCMC Buttweld Fitting
ASME SB366-WPNCMC Seamless Fittings
B366 gr WPNCMC ERW Fittings
ASME SB366-WPNCMC Welded Fittings
B366 WPNCMC Fabricated Pipe Fittings
ASTM B366 GRADE WPNCMC Bevel Ends Pipe Fittings

OD DN15-DN1200
CONNECTION Welding
BEDING RADIUS R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASME SB366 WPNCMC Pipe Fitting
RANGE ½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM B366-WPNCMC Buttweld Fitting

DEGREE
OF ELBOW

Angle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D, 4D, 5D, 6D, 7D-40D .
Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO

PROCESS Push, Press, Forge, Cast, etc.
TEST

EN 10204/3.1B
Raw Materials Certificate
100% Radiography Test Report
Third Party Inspection Report(charged)





Stamping

Stamping forming elbow is the earliest forming process applied to batch production of seamless elbow, which has been replaced by hot pushing method or other forming processes in the production of elbow with common specifications. However, in some specifications of elbow, the production quantity is small, the wall thickness is too thick or too thin.

The product is still in use when there are special requirements. The pipe blank with the same outer diameter as the elbow is used for the stamping forming of the elbow, and the press is used to directly press the elbow in the mold.

Before stamping, the tube blank is placed on the lower die, the inner core and end die are loaded into the tube blank, the upper die moves downward and starts to press, and the elbow is formed by the constraint of the outer die and the support of the inner die.

Compared with the hot pressing process, the appearance quality of the stamping process is not as good as the former; The outer arc of the stamping elbow is in the tensile state when forming, and there is no extra metal in other parts to compensate, so the wall thickness at the outer arc is reduced by about 10%. However, due to its applicability to single-piece production and low cost, the stamping elbow process is mostly used for the manufacture of small batches of thick wall elbows.

Stamping elbow is divided into cold stamping and hot stamping, which are usually selected according to material properties and equipment capacity.

 A335 P11 P22 Sch80 9-180 Degree Steel Pipe Elbow Fittings S31803  S32750 0
A335 P11 P22 Sch80 9-180 Degree Steel Pipe Elbow Fittings S31803  S32750 1




power

Standard number description

GB2000 Typical Design Manual for Steam and Water Piping Parts and Components of Thermal Power Plant

DL/T515-93 Power station elbow

D-GD87-1101 Typical design of pipe parts and components

Chemical standards of pipe fittings:

Standard number description

HGJ514 carbon steel and low alloy steel seamless butt welded pipe fittings

HGJ528 steel butt welded pipe fittings

HGJ10 forged steel socket welding pipe fittings

HGJ529 forged steel socket welding, threaded and butt welding pipe set

HGJ-44-76-91 Steel pipe flange, gasket and fastener

HG20592-20635 Steel pipe flange, gasket and fastener

Sinopec

Standard number description

SH3406-1996 petrochemical steel pipe flange

SH3408-1996 steel butt-welding seamless pipe fittings

SH3409-1996 forged steel socket welding pipe fittings

SH3410-1996 Forged steel socket welding pipe fittings

SH3065-1994 Technical standard for sharp bends of petrochemical tubular furnace

country

Standard number description

GB12459-2005 Steel butt-welding seamless pipe fittings

GB/T13401 Steel Plate Butt-welding Pipe Fittings

GB/T14383 Forged Steel Socket Welding Fittings

GB/T10752-1995 Butt-welded joints of marine steel pipes

GB/T17185-1995 Steel flanged pipe fittings

The pipe fittings shall comply with the following petroleum standards:

Standard number description

SY/T0510-1998 Steel butt-welding pipe fittings

SY/T5257-2004 Steel elbow

02S403 National Building Standard for Steel Pipe Fittings

Marine

CB/T3590-94 aluminum brass elbow

A335 P11 P22 Sch80 9-180 Degree Steel Pipe Elbow Fittings S31803  S32750 2

A335 P11 P22 Sch80 9-180 Degree Steel Pipe Elbow Fittings S31803  S32750 3
A335 P11 P22 Sch80 9-180 Degree Steel Pipe Elbow Fittings S31803  S32750 4
