SCH10 P12 / P22 / P91 Steel Pipe Elbow Size 1/2" To 36"

Product Details:
Place of Origin: China
Brand Name: hongcheng
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015, IEI
Model Number: 1/2" TO 36"
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Discussion
Packaging Details: Plywood Cases or Pallets
Delivery Time: 7-15 work days
Payment Terms: T/T, L/C at sight
Supply Ability: 2 Million Ton/Year
  • Detail Information
  • Product Description

Detail Information

Model Number:: 1/2"-36" Material Grade:: WP11, WP22, WP5, P9,P91, P92
Standard:: Astm A234 Astm A335 Wall Thickness:: SCH10, SCH20, SCH30, STD, SCH40, SCH60, XS, SCH80, SCH100, SCH120, SCH140, SCH160 And XXS
DEGREE:: 45° 90° 180° Packaging Details:: According To Client Requirements/ Wooden Case Packing
Type :: Seamless / Fabricated
High Light:

p12 steel pipe elbow

,

sch10 steel pipe elbow

,

36 inch seamless pipe elbow

Product Description

Astm A335 Alloy Steel Seamless Elbow P9 / P11 / P12 / P22 / P91 Size 1/2" To 36"



BUTT-WELDING PIPE FITTINGS DETAILS

MATERIAL

Carbon Steel :

ASTM, A234WPB, A234WPC, A420WPL6 ,Q235,10#, A3, Q235A, 20G,16Mn,

DIN St37, St45.8, St52.4,St.35.8,St.35.8.

Stainless Steel:

1Cr18Ni9Ti 0Cr18Ni9 00Cr19Ni10 0Cr17Ni12Mo2Ti

00Cr17Ni14Mo2 304 304L 316 316L

Alloy Steel:

16Mn Cr5Mo 12Cr1MoV 10CrMo910 15CrMo 12Cr2Mo1,

A335P22 St45.8, ASTM A860 WPHY X42 X52 X60 X70

STANDARD

ASTM / JIS / DIN / BS / GB/GOST

MODEL

1.Tee(Straight and Reducing) 2.180 DEG Return

3.Elbow (45/90/180 DEG) 4.Cap

5. Reducer(Concentric and Eccentric)

TYPE

Seam Or Seamless

ELBOW DEGREE

45 degree, 90 degree, 180 degree

SURFACE

Black Paint, Anti Rust Oil, Hot-Dipped Galvanize

WALL THICKNESS

SCH5S,SCH10S,SCH10,SCH20,SCH30,SCH40,STD,XS,SCH60,

SCH80,SCH100,SCH120,SCH140,SCH160,XXS,2MM

SIZE

1/2"-48"(Dn15-Dn1200)

CONNECTION

Welding

SHAPE

Equal, Reducing

CERTIFICATE

ISO9001

APPLICATION

Petroleum, chemical, power, gas, metallurgy, shipbuilding, construction, etc

RELATED PRODUCTS

1. Carbon steel nipples and sockets

2. Flanges

3. Malleable iron pipe fittings

4. Pipes

5. High-pressure fittings

6. Valves

7. P.T.F.E .thread seal tape

8. Brass fittings

9. Ductile iron pipe fittings

10. Copper fittings

11. Sanitary fittings, etc,.

12. Grooved fittings

Customers’ drawings or designs are available.

PACKAGE

1> 1/2" - 2" in cartons.

2>Above 2" in wooden cases.

Big size is workable by pallets.

DELIVERY DETAILS

According to the quantities and specifications of each order.

Normal delivery time is from 15to 20 days after receiving the deposit.

SCH10 P12 / P22 / P91 Steel Pipe Elbow Size 1/2" To 36" 0

Unit : inch

Nominal

Pipe

Size

Outside Dia.

(OD)

Wall Thickness (T)

90o L/R Elbow Center To End A

45o L/R Elbow Center To End B

90o S/R Elbow Center To End A

Sch.5S

Sch.10S

Sch.40S

Sch.80S

1/2

0.840

0.065

0.083

0.109

0.147

1.50

0.625



3/4

1.050

0.065

0.083

0.113

0.154

1.12

0.438



1

1.315

0.065

0.109

0.133

0.179

1.50

0.875

1.00

1-1/4

1.660

0.065

0.109

0.140

0.191

1.88

1.00

1.25

1-1/2

1.900

0.065

0.109

0.145

0.200

2.25

1.12

1.50

2

2.375

0.065

0.109

0.154

0.218

3.00

1.38

2.00

2-1/2

2.875

0.083

0.120

0.203

0.276

3.75

1.75

2.50

3

3.500

0.083

0.120

0.216

0.300

4.50

2.00

3.00

4

4.500

0.083

0.120

0.237

0.337

6.00

2.50

4.00

5

5.563

0.109

0.134

0.258

0.375

7.50

3.12

5.00

6

6.625

0.109

0.134

0.280

0.432

9.00

3.75

6.00

8

8.625

0.109

0.148

0.322

0.500

12.00

5.00

8.00

10

10.750

0.134

0.165

0.375

0.500

15.00

6.25

10.00

12

12.750

0.156

0.180

0.375

0.500

18.00

7.50

12.00

14

14.000

0.156

0.250

0.375

0.500

21.00

8.75

14.00

16

16.000

0.165

0.250

0.375

0.500

24.00

10.00

16.00

18

18.000

0.165

0.250

0.375

0.500

27.00

11.25

18.00

20

20.000

0.188

0.250

0.375

0.500

30.00

12.50

20.00

24

24.000

0.218

0.250

0.375

0.500

36.00

13.50

24.00

Chemical composition(%):

Grade

C

Mn

P≤

S≤

Si

Cr

Mo

P11

0.05-0.15

0.30-0.60

0.025

0.025

0.50-1.00

1.00-1.50

0.44-0.65

P22

0.05-0.16

0.30-0.60

0.025

0.025

≤0.50

1.90-2.60

0.87-1.13

P5

≤0.15

0.30-0.60

0.025

0.025

≤0.50

4.00-6.00

0.45-0.65

P9

≤0.15

0.30-0.60

0.025

0.025

0.25-1.00

8.00-10.00

0.90-1.10

P91

0.08-0.12

0.30-0.60

0.020/0.010

0.020/0.010

0.02-0.50

8.00-9.50

0.85-1.05

P92

0.07-0.13

0.30-0.60

0.020/0.010

0.020/0.010

≤0.50

8.50-9.50

0.30-0.60



SCH10 P12 / P22 / P91 Steel Pipe Elbow Size 1/2" To 36" 1

Company Profile

China Hebei Hongcheng Pipe Industry Co., Ltd.established in 2009, is located in Jiading District, Shanghai, China. It is an intelligent enterprise focusing on the development, production and service of industrial pressure pipe fittings. Its products range from elbow, tee, reducer, flanging, elbow, pipe cap, flange, forged socket welded pipe fittings, forged threaded pipe fittings and other pipe joints, mainly serving marine, petrochemical and petrochemical industries Petroleum, chemical, machinery, shipping, power, metallurgy, natural gas, urban engineering equipment, steel and other industries to provide high-quality industrial metal pipe fittings and engineering materials overall support outsourcing solutions and one-stop supply services. Our product standards include American Standard ASME / ANSI, German standard DIN, European standard en10241, British Standard BS, national standard GB and domestic industry standards. The product materials meet ASTM carbon steel a234, WPB, wphy, A105, A106 gr. B, 20 #, 20g, 16Mn, stainless steel 304 / 304L, 316 / 316L, 321, wp317l, 316Ti, duplex stainless steel and alloy steel S31803 / S32205, S32750, s32760, s31254, A182 F51, A182 f53254smo Alloy Steel ASTM a234, Wp1, wp5, wp9, wp11, wp22, wp91, WB36, ASTM A182, F5, F9, F11, F22, F91, etc. We always adhere to the business philosophy of "service creates value", build a global supply and service system for industrial metal pipe fittings, and strive to become a global leader in MRO industrial pipe fittings distribution industry.

The epidemic has brought challenges to the global metal pipe fitting industry, but also new development opportunities. Hebei Hongcheng will be based on the global market, closely combined with the characteristics of the industry, dig deep into customer applications, solve users' pain points, rely on strong R & D strength, integrate cutting-edge technical ideas, quickly respond to the changing needs of customers, and provide reliable, safe, high-quality, high-quality and high-quality products for customers in the industry Easy to expand customized requirements and pipeline system engineering solutions.





SCH10 P12 / P22 / P91 Steel Pipe Elbow Size 1/2" To 36" 2

FAQ:

Q1: How to order?

1. To specity standard and the thickness.

2. To specity surface treatment.

3. To specity figure size and quantity.

Q2: After sales service?

Quality are promised.We have a dedicated after-sales department to be responsible for all subsequent work after delivery.

Q3: Can I have a sample order for pipe fittings?

Yes, we welcome sample order to test and check quality.Mixed samples are acceptable.

Q4: Do you offer guarantee for the products?

Yes, we offer almost 20 years warranty to our products.
