20G Seamless Boiler Tube , High Pressure Steel Pipe 12Cr1MoVG ODM

Product Details:
Place of Origin: China
Brand Name: HongCheng
Certification: PED、ABS、BV、DNV、GL、LR、SGS、IEI
Model Number: 1"TO36 "
Payment & Shipping Terms:
Minimum Order Quantity: 0.5Ton
Price: 0.5 Ton US $2843/ Ton;>3 Tons US $2510/ Ton
Packaging Details: Standard export seaworthy package,or as required
Delivery Time: 7-15 work days
Payment Terms: L/C, D/P, T/T
Supply Ability: 2 Million Ton/Year
  • Detail Information
  • Product Description

Detail Information

Product Name:: High Pressure Boiler Steel Pipe Standard:: ASTM
Payment Terms:: 30%TT Advance + 70% Balance Surface Treatment:: Cold Rolled
Section Shape:: Round Length:: 12M, 6m, 6.4M, 6M, 12M/Customed
Thickness:: 2-50 Mm End Protector:: Plastic Pipe Cap
Surface:: Black Paint, Varnished,Galvanized,Customed Packaging Details: Standard Package Or As Requirements.
High Light:

20G Seamless Boiler Tube HongCheng

,

6.4M 12Cr1MoVG Seamless Boiler Tube

,

ODM High Pressure Steel Pipe

Product Description

12Cr1MoVG 12Cr1MoVG 20G Seamless Boiler Tube Alloy Steel Pipe High Pressure Boiler Pipe

Introduction

Alloy seamless steel pipe is a kind of seamless steel pipe, its performance is much higher than that of general seamless steel pipe, because this kind of steel pipe contains more Cr, its high temperature, low temperature and corrosion resistance performance is not compared with other seamless steel pipe, so alloy pipe is widely used in petroleum, chemical industry, electric power, boiler and other industries.

Alloy seamless steel pipe contains elements such as silicon, manganese, chromium, nickel, molybdenum, tungsten, vanadium, titanium, niobium, zirconium, cobalt, aluminum, copper, boron, rare earth, etc.

Alloy seamless steel pipe (Seamless Steel Tube) with hollow section, no joints around the strip steel. The steel pipe has a hollow section and is widely used as a pipeline for conveying fluid, such as oil, natural gas, gas, water and some solid materials. Compared with solid steel such as round steel, alloy seamless steel pipe is light weight when bending and torsion strength is the same. It is an economic section steel, which is widely used in the manufacture of structural parts and mechanical parts, such as oil conveying, stair handrails, bicycle frames and steel scaffolding used in construction. Making ring parts with alloy seamless steel pipe can improve material utilization, simplify manufacturing process, and save material and processing time, such as rolling bearing ring, Jack sleeve and so on. Steel pipe has been widely used to manufacture. Alloy seamless steel pipe or all kinds of conventional weapons indispensable materials, gun barrel, barrel and so on must be made of steel pipe. In addition, when the ring section is subjected to internal or external radial pressure, the force is more uniform, so most alloy seamless steel tubes are circular tubes

Production process

Hot rolling (extruded seamless steel pipe): pipe billet → heating → perforation → three-roll oblique rolling, continuous rolling or extrusion → pipe → diameter (or diameter reduction) cooling pipe straightening → hydraulic test (or flaw detection) marking → storage.

cold drawn (rolled) seamless steel tube billet → heating → perforation → head → annealing → pickling → oiling (copper plating), multi-pass cold drawing (cold rolling)→ billet tube → heat treatment, straightening → water pressure test (flaw detection), marking → storage

Product Description

Standard

GB/T5310,GB/T3087ASTM A355,ASTM A106, ASTM A53, API 5L Gr.B, DIN17175,DIN1629

Material

20G,15Cr1MoVG,12Cr1MoVGASTM A106B, ASTM A53B, API 5L Gr.B,ST52,

ST37,ST44,SAE1010/1020/1045,S45C/CK45,SCM435,AISI4130/4140

Outer diameter

10.3mm-609.6mm

Wall thickness

1.5mm-30mm

Length

3m-12m, random or fixed, as the clients' requests

Technology

Hot Rolled

Tolerance

Control with in the standard, OD:+/-0.2mm, WT:+/-0.2mm



Advantages

1.Short delivery time

2.Quality assurance

3.Competitive price

4.Free Sample



20G Seamless Boiler Tube , High Pressure Steel Pipe 12Cr1MoVG ODM 0

20G Seamless Boiler Tube , High Pressure Steel Pipe 12Cr1MoVG ODM 1

20G Seamless Boiler Tube , High Pressure Steel Pipe 12Cr1MoVG ODM 2

20G Seamless Boiler Tube , High Pressure Steel Pipe 12Cr1MoVG ODM 3

20G Seamless Boiler Tube , High Pressure Steel Pipe 12Cr1MoVG ODM 4

20G Seamless Boiler Tube , High Pressure Steel Pipe 12Cr1MoVG ODM 5

20G Seamless Boiler Tube , High Pressure Steel Pipe 12Cr1MoVG ODM 6
