Q345b Q235d Seamless Steel Pipe , Sa106c 106b High Pressure Steel Tube

Product Details:
Place of Origin: China
Brand Name: HongCheng
Certification: PED、ABS、BV、DNV、GL、LR、SGS、IEI
Model Number: 1"TO36 "
Payment & Shipping Terms:
Minimum Order Quantity: 0.5Ton
Price: 0.5 Ton US $2843/ Ton;>3 Tons US $2510/ Ton
Packaging Details: Standard export seaworthy package,or as required
Delivery Time: 7-15 work days
Payment Terms: L/C, D/P, T/T
Supply Ability: 2 Million Ton/Year
  • Detail Information
  • Product Description

Detail Information

Product Name:: High Pressure Boiler Steel Pipe Standard:: ASTM
Payment Terms:: 30%TT Advance + 70% Balance Surface Treatment:: Cold Rolled
Section Shape:: Round Length:: 12M, 6m, 6.4M, 6M, 12M/Customed
Thickness:: 2-50 Mm End Protector:: Plastic Pipe Cap
High Light:

Q345b Seamless Steel Pipe

,

Sa106c Q235d Seamless Steel Pipe

,

SQ235d Sa106c High Pressure Steel Tube

Product Description

High Pressure Boiler Pipe Q345b Q235d Sa106c 106b Seamless Steel Pipe

Introduction

Alloy seamless steel pipe is a kind of seamless steel pipe, its performance is much higher than that of general seamless steel pipe, because this kind of steel pipe contains more Cr, its high temperature, low temperature and corrosion resistance performance is not compared with other seamless steel pipe, so alloy pipe is widely used in petroleum, chemical industry, electric power, boiler and other industries.

Alloy seamless steel pipe contains elements such as silicon, manganese, chromium, nickel, molybdenum, tungsten, vanadium, titanium, niobium, zirconium, cobalt, aluminum, copper, boron, rare earth, etc.

Alloy seamless steel pipe (Seamless Steel Tube) with hollow section, no joints around the strip steel. The steel pipe has a hollow section and is widely used as a pipeline for conveying fluid, such as oil, natural gas, gas, water and some solid materials. Compared with solid steel such as round steel, alloy seamless steel pipe is light weight when bending and torsion strength is the same. It is an economic section steel, which is widely used in the manufacture of structural parts and mechanical parts, such as oil conveying, stair handrails, bicycle frames and steel scaffolding used in construction. Making ring parts with alloy seamless steel pipe can improve material utilization, simplify manufacturing process, and save material and processing time, such as rolling bearing ring, Jack sleeve and so on. Steel pipe has been widely used to manufacture. Alloy seamless steel pipe or all kinds of conventional weapons indispensable materials, gun barrel, barrel and so on must be made of steel pipe. In addition, when the ring section is subjected to internal or external radial pressure, the force is more uniform, so most alloy seamless steel tubes are circular tubes

Production process

Hot rolling (extruded seamless steel pipe): pipe billet → heating → perforation → three-roll oblique rolling, continuous rolling or extrusion → pipe → diameter (or diameter reduction) cooling pipe straightening → hydraulic test (or flaw detection) marking → storage.

cold drawn (rolled) seamless steel tube billet → heating → perforation → head → annealing → pickling → oiling (copper plating), multi-pass cold drawing (cold rolling)→ billet tube → heat treatment, straightening → water pressure test (flaw detection), marking → storage

Q345b Q235d Seamless Steel Pipe , Sa106c 106b High Pressure Steel Tube 0

standard the name of a shop tensile strength (MPa) Yield strength (MPa) (%) of elongation hardness
GB3087 10 335~475 ≥195 ≥24 /
20 410~550 ≥245 ≥20 /
GB5310 20G 410~550 ≥245 ≥24 /
20MnG ≥415 ≥240 ≥22 /
25MnG ≥485 ≥275 ≥20 /
15CrMoG 440~640 ≥235 ≥21 /
12Cr2MoG 450~600 ≥280 ≥20 /
12Cr1MoVG 470~640 ≥255 ≥21 /
12Cr2MoWVTiB 540~735 ≥345 ≥18 /
10Cr9Mo1VNb ≥585 ≥415 ≥20 /
ASME SA210 SA210A-1 ≥415 ≥255 ≥30 ≤143HB
SA210C ≥485 ≥275 ≥30 ≤179HB
ASME SA213 SA213 T11 ≥415 ≥205 ≥30 ≤163HB
SA213 T12 ≥415 ≥220 ≥30 ≤163HB
SA213 T22 ≥415 ≥205 ≥30 ≤163HB
SA213 T23 ≥510 ≥400 ≥20 ≤220HB
SA213 T91 ≥585 ≥415 ≥20 ≤250HB
SA213 T92 ≥620 ≥440 ≥20 ≤250HB
DIN17175 ST45.8/Ⅲ 410~530 ≥255 ≥21 /
  15Mo3 450~600 ≥270 ≥22
13CrMo44 440~590 ≥290 ≥22 /
10CrMo910 480~630 ≥280 ≥20

/







Q345b Q235d Seamless Steel Pipe , Sa106c 106b High Pressure Steel Tube 1

Q345b Q235d Seamless Steel Pipe , Sa106c 106b High Pressure Steel Tube 2



Q345b Q235d Seamless Steel Pipe , Sa106c 106b High Pressure Steel Tube 3

Q345b Q235d Seamless Steel Pipe , Sa106c 106b High Pressure Steel Tube 4

Q345b Q235d Seamless Steel Pipe , Sa106c 106b High Pressure Steel Tube 5

Q345b Q235d Seamless Steel Pipe , Sa106c 106b High Pressure Steel Tube 6
