Product Details:
Place of Origin:	China
Brand Name:	hongcheng
Certification:	PED、ABS、BV、DNV、GL、LR、SGS、IEI
Model Number:	18-1219mm
Payment & Shipping Terms:
Minimum Order Quantity:	0.5Ton
Price:	Negotiable
Packaging Details:	Standard export seaworthy package,or as required
Delivery Time:	7-15 work days
Payment Terms:	L/C, D/P, T/T
Supply Ability:	2 Million Ton/Year

Detail Information
Standard:	ASTM A335, ASTM A213, JIS G3458, JIS A3462, DIN17175, GB5310, GB9948	Material:	P1, P2, P12, P11, P22, P5, P9, P91, P92,T1, T2, T11,T12, T5, T9, T22, ST52, X42, X46,X52,X60,X70,X80,X100,15CrMo,Cr5Mo,10CrMo910,12Cr2Mo,13CrMo44,12CrMo195,42CrMo,42CrMO4, X12CrMo91,12CrMo,etc
Wall Thickness:	1mm~120mm	Length:	12m, 11.8m, 6m, 5.8m Or As Required
Application:	Alloy Steel Pipe Applies To Petroleum, Chemical Industry, Electric Power, Boiler, High Temperature Resistant, Low Temperature Resistant, Corrosion Resistant Part. The Size Of Alloy Steel Pipe Can Be Made According To The Customers Requirements.	Packaging Details:	Plywood Case And Plywood Pallet
Appearance::	Sandblasting, Rolling Sand Or Paint Surface	Application::	Petrochemical, Electric Power, Gas, Metallurgy, Shipbuilding, Etc
High Light:	seamless alloy steel pipe 6meter , 120mm seamless alloy steel pipe , 120mm alloy steel tube

Description	alloy pipe, seamless black A335 P1 steel pipe, seamless alloy pipe, welded alloy pipe
Standard	ASTM A335, ASTM A213, JIS G3458, JIS A3462, DIN17175, GB5310, GB9948
Material	P1, P2, P12, P11, P22, P5, P9, P91, P92,T1, T2, T11,T12, T5, T9, T22, ST52, X42, X46, X52, X60, X70,X80,X100, 15CrMo,Cr5Mo,10CrMo910,12Cr2Mo,13CrMo44,12CrMo195,42CrMo,42CrMO4, x12CrMo91,12CrMo,etc
Shape	Round,Square,Rectangular
Outside Diameter	6 mm~2500mm
Wall thickness	1mm~120mm
Length	12m, 11.8m, 6m, 5.8m or as required
Surface	Black painted,PE coated,HDPE,Varnished,Galvanized ,etc
Price term	Ex-Work,FOB,CNF,CFR,CIF,etc
Payment term	TT,L/C,D/P,Western Union,etc
Package	Standard export package,suit for all kinds of transport.
Export to	Poland,India,Dubai,Korea,Thailand,Viet Name,Indonesia,Brazil,Saudi Arabia,Canada,Mexico,Peru, USA,Canada,Kuwait,Oman,Peru,Singapore,South Africa,Oman,Korea,Thailand,etc
MOQ	500Kg
Application	Alloy A335 P1 steel pipe applies to petroleum, chemical industry, electric power, boiler, high temperature resistant, low temperature resistant, corrosion resistant part. The size of Alloy A335 P1 steel pipe can be made according to the customers requirements.
Container Size	20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)
Contacts	If you have any questions, please feel free to contact me We are sure your inquiry or attention will get prompt attention.

Grade	Chemical Composition%
Grade	C	Si	Mn	P, S Max	Cr	Mo	Ni Max	V	Al Max
T2	0.10~0.20	0.10~0.30	0.30~0.61	0.025	0.50~0.81	0.44~0.65	–	–	–
T11	0.05~0.15	0.50~1.00	0.30~0.60	0.025	1.00~1.50	0.44~0.65	–	–	–
T12	0.05~0.15	Max 0.5	0.30~0.61	0.025	0.80~1.25	0.44~0.65	–	–	–
T22	0.05~0.15	Max 0.5	0.30~0.60	0.025	1.90~2.60	0.87~1.13	–	–	–
T91	0.07~0.14	0.20~0.50	0.30~0.60	0.02	8.0~9.5	0.85~1.05	0.4	0.18~0.25	0.015
T92	0.07~0.13	Max 0.5	0.30~0.60	0.02	8.5~9.5	0.30~0.60	0.4	0.15~0.25	0.015
Grade	Chemical Composition%				Mechanical Properties
Grade	W	B	Nb	N	T. S	Y. P	Elongation	Hardness
T2	–	–	–	–	≥ 415MPa	≥ 205MPa	≥ 30%	163HBW(85HRB)
T11	–	–	–	–	≥ 415MPa	≥ 205MPa	≥ 30%	163HBW(85HRB)
T12	–	–	–	–	≥ 415MPa	≥ 220MPa	≥ 30%	163HBW(85HRB)
T22	–	–	–	–	≥ 415MPa	≥ 205MPa	≥ 30%	163HBW(85HRB)
T91	–	–	0.06~0.10	0.03~0.07	≥ 585MPa	≥ 415MPa	≥ 20%	250HBW(25HRB)
T92	1.50~2.00	0.001~0.006	0.04~0.09	0.03~0.07	≥ 620MPa	≥ 440MPa	≥ 20%	250HBW(25HRB)

Outside Diameter	OD Tolerance	WT Tolerance	Ovality Tolerance	Cut Length Tolerance
OD≤ 12, 7 mm	± 0, 13 mm	± 15 %	–	+ 3, 18 mm, – 0 mm
12, 7 mm < OD ≤ 38, 1 mm	± 0, 13 mm	± 10 %	max, 1, 65 mm	+ 3, 18 mm, – 0 mm
38, 1 mm < OD ≤ 88, 9 mm	± 0, 25 mm	± 10 %	max, 2, 41 mm	+ 4, 76 mm, – 0 mm

A213/Smes Sa213 1mm~120mm Seamless Alloy Steel Pipe 6meter Fixed Length

seamless alloy steel pipe 6meter

120mm seamless alloy steel pipe

120mm alloy steel tube

A213/Smes Sa213 1mm~120mm 6-meter fixed length or seamless alloy steel pipe as required

ASTM A213/ASME SA213 T2, T11, T12, T22, T91, T92 Chemical Composition and Mechanical Properties

Grade

Chemical Composition%

C

Si

Mn

P, S Max

Cr

Mo

Ni Max

V

Al Max

T2

0.10~0.20

0.10~0.30

0.30~0.61

0.025

0.50~0.81

0.44~0.65

–

–

–

T11

0.05~0.15

0.50~1.00

0.30~0.60

0.025

1.00~1.50

0.44~0.65

–

–

–

T12

0.05~0.15

Max 0.5

0.30~0.61

0.025

0.80~1.25

0.44~0.65

–

–

–

T22

0.05~0.15

Max 0.5

0.30~0.60

0.025

1.90~2.60

0.87~1.13

–

–

–

T91

0.07~0.14

0.20~0.50

0.30~0.60

0.02

8.0~9.5

0.85~1.05

0.4

0.18~0.25

0.015

T92

0.07~0.13

Max 0.5

0.30~0.60

0.02

8.5~9.5

0.30~0.60

0.4

0.15~0.25

0.015

Grade

Chemical Composition%

Mechanical Properties
