Product Details:
Place of Origin:	China
Brand Name:	hongcheng
Certification:	PED、ABS、BV、DNV、GL、LR、SGS、IEI
Model Number:	18-1219mm
Payment & Shipping Terms:
Minimum Order Quantity:	0.5Ton
Price:	Negotiable
Packaging Details:	Standard export seaworthy package,or as required
Delivery Time:	7-15 work days
Payment Terms:	L/C, D/P, T/T
Supply Ability:	2 Million Ton/Year

Detail Information
Standard:	ASTM A335, ASTM A213, JIS G3458, JIS A3462, DIN17175, GB5310, GB9948	Material:	P1, P2, P12, P11, P22, P5, P9, P91, P92,T1, T2, T11,T12, T5, T9, T22, ST52, X42, X46,X52,X60,X70,X80,X100,15CrMo,Cr5Mo,10CrMo910,12Cr2Mo,13CrMo44,12CrMo195,42CrMo,42CrMO4, X12CrMo91,12CrMo,etc
Wall Thickness:	1mm~120mm	Length:	12m, 11.8m, 6m, 5.8m Or As Required
Application:	Alloy Steel Pipe Applies To Petroleum, Chemical Industry, Electric Power, Boiler, High Temperature Resistant, Low Temperature Resistant, Corrosion Resistant Part. The Size Of Alloy Steel Pipe Can Be Made According To The Customers Requirements.	Packaging Details:	Plywood Case And Plywood Pallet
High Light:	Smes Sa213 Alloy Seamless Steel Pipe , Boiler Alloy Seamless Steel Pipe , Heat Exchanger Seamless Alloy Steel Pipe

Grade	Chemical Composition%
Grade	C	Si	Mn	P, S Max	Cr	Mo	Ni Max	V	Al Max
T2	0.10~0.20	0.10~0.30	0.30~0.61	0.025	0.50~0.81	0.44~0.65	–	–	–
T11	0.05~0.15	0.50~1.00	0.30~0.60	0.025	1.00~1.50	0.44~0.65	–	–	–
T12	0.05~0.15	Max 0.5	0.30~0.61	0.025	0.80~1.25	0.44~0.65	–	–	–
T22	0.05~0.15	Max 0.5	0.30~0.60	0.025	1.90~2.60	0.87~1.13	–	–	–
T91	0.07~0.14	0.20~0.50	0.30~0.60	0.02	8.0~9.5	0.85~1.05	0.4	0.18~0.25	0.015
T92	0.07~0.13	Max 0.5	0.30~0.60	0.02	8.5~9.5	0.30~0.60	0.4	0.15~0.25	0.015
Grade	Chemical Composition%				Mechanical Properties
Grade	W	B	Nb	N	T. S	Y. P	Elongation	Hardness
T2	–	–	–	–	≥ 415MPa	≥ 205MPa	≥ 30%	163HBW(85HRB)
T11	–	–	–	–	≥ 415MPa	≥ 205MPa	≥ 30%	163HBW(85HRB)
T12	–	–	–	–	≥ 415MPa	≥ 220MPa	≥ 30%	163HBW(85HRB)
T22	–	–	–	–	≥ 415MPa	≥ 205MPa	≥ 30%	163HBW(85HRB)
T91	–	–	0.06~0.10	0.03~0.07	≥ 585MPa	≥ 415MPa	≥ 20%	250HBW(25HRB)
T92	1.50~2.00	0.001~0.006	0.04~0.09	0.03~0.07	≥ 620MPa	≥ 440MPa	≥ 20%	250HBW(25HRB)

Outside Diameter	OD Tolerance	WT Tolerance	Ovality Tolerance	Cut Length Tolerance
OD≤ 12, 7 mm	± 0, 13 mm	± 15 %	–	+ 3, 18 mm, – 0 mm
12, 7 mm < OD ≤ 38, 1 mm	± 0, 13 mm	± 10 %	max, 1, 65 mm	+ 3, 18 mm, – 0 mm
38, 1 mm < OD ≤ 88, 9 mm	± 0, 25 mm	± 10 %	max, 2, 41 mm	+ 4, 76 mm, – 0 mm

Smes Sa213 Alloy Seamless Steel Pipe For Boiler Heat Exchanger

Smes Sa213 Alloy Seamless Steel Pipe

Boiler Alloy Seamless Steel Pipe

Heat Exchanger Seamless Alloy Steel Pipe

Astm A213 / Smes Sa213 Alloy Steel Seamless Tubes For Boiler Heat Exchanger Alloy Seamless Steel Pipe

Hongcheng Company supply huge qty of Cr-Mo Alloy seamless pipe and tube , and export more than 40 countries . Our alloy seamless tube be width used in boiler and heating.

ASTM A213/ASME SA213 T2, T11, T12, T22, T91, T92 Chemical Composition and Mechanical Properties

Grade

Chemical Composition%

C

Si

Mn

P, S Max

Cr

Mo

Ni Max

V

Al Max

T2

0.10~0.20

0.10~0.30

0.30~0.61

0.025

0.50~0.81

0.44~0.65

–

–

–

T11

0.05~0.15

0.50~1.00

0.30~0.60

0.025

1.00~1.50

0.44~0.65

–

–

–

T12

0.05~0.15

Max 0.5

0.30~0.61

0.025

0.80~1.25

0.44~0.65

–

–

–

T22

0.05~0.15

Max 0.5

0.30~0.60

0.025

1.90~2.60

0.87~1.13

–

–

–

T91

0.07~0.14

0.20~0.50

0.30~0.60

0.02

8.0~9.5

0.85~1.05

0.4

0.18~0.25

0.015

T92

0.07~0.13

Max 0.5

0.30~0.60

0.02

8.5~9.5

0.30~0.60

0.4

0.15~0.25

0.015

Grade

Chemical Composition%
