Hebei Hongcheng Pipe Fittings Co., Ltd.

Astm A420 14inch S100 Alloy Steel Fittings Seamless Forged Butt Welded Pipe

Product Details:
Place of Origin: China
Brand Name: hongcheng
Certification: PED、ABS、BV、DNV、GL、LR、SGS、IEI
Model Number: 1/2" TO 72 "
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Packaging Details: Plywood Cases or Pallets
Delivery Time: 7-15 work days
Payment Terms: L/C, D/P, T/T
Supply Ability: 200,000 tons/year
  • Detail Information
  • Product Description

Detail Information

Place Of Origin:: China Payment Terms: T/T, L/C At Sight
Size: 1/8"-2", 1/2"-48", 1/2"-6", DN15-DN1200 1/2’’~48’’(Seamless);16’’~72’’(Welded) Standard: ASTM A234. ASTM A420, ASTM A860
MATERIAL:: P9/P11/P12/P22/P91/92 Application :: Gas And Oil Pipes, Petroleum Gas, Joining Pipe Lines
Technics: Forged,Casting,Welding Surface Treatment:: Sandblasting, Sand Rolling, Paint Spraying Surface
High Light:

Astm A420 Alloy Steel Fittings

,

Astm A420 Butt Welded Pipe

,

14inch Butt Welded Pipe

Product Description

Astm A420 14 "S100 Alloy Steel Fittings Seamless Butt Welded Forged Pipe

Tees are also known as pipe fittings or tee fittings, tee joints, etc. Mainly used to change the direction of the fluid, used in the main pipe or branch pipe. It can be classified by pipe diameter. Generally, it is made of carbon steel, cast steel, alloy steel, stainless steel, copper, aluminum alloy, plastic, argon carbide, PVC, and other materials.

Classified by pipe diameter:

The nozzle ends of equal diameter tees are of the same size;

The main pipe size of the reducing tee is the same, while the branch pipe size is smaller than the main pipe size.

By process

1. Hydraulic bulging

Hydraulic bulging of tees is a forming process that expands branch pipes through axial compensation of metal materials. The process is to use a dedicated hydraulic press to inject liquid into the tube blank with the same diameter as the tee, and press the tube blank through synchronous centering movement of the two horizontal side cylinders of the hydraulic press. The volume of the tube blank becomes smaller after being squeezed, and the pressure of the liquid in the tube blank increases as the volume of the tube blank becomes smaller. When the pressure required for the expansion of the tee branch pipe is reached, the metal material flows along the inner cavity of the mold and expands out of the branch pipe under the dual action of the side cylinder and the liquid pressure in the tube blank.

The hydraulic bulging process of the tee can be formed in one step, with high production efficiency; The wall thickness of the main pipe and shoulder of the tee increases.

Due to the large tonnage of equipment required for the hydraulic bulging process of seamless tees, it is mainly used in the manufacturing of standard wall thickness tees smaller than DN400 in China. The suitable forming materials are low carbon steel, low alloy steel, and stainless steel with relatively low cold work hardening tendency, including some non ferrous metal materials, such as copper, aluminum, and titanium.



2. Hot pressing forming

Cold drawn tee

Cold drawn tee

Hot pressing of a tee involves flattening a tube blank larger than the diameter of the tee to about the size of the tee diameter and opening a hole in the part where the branch pipe is stretched; The tube blank is heated, placed into a forming die, and a stamping die for drawing the branch pipe is inserted into the tube blank; Under the action of pressure, the tube blank is compressed radially. During the radial compression process, the metal flows in the direction of the branch pipe and forms a branch pipe under the drawing of the die. The entire process is formed through the radial compression of the tube blank and the stretching process of the branch pipe. Unlike hydraulic bulging tees, the metal of hot pressed tees is compensated by the radial motion of the tube blank, so it is also known as a radial compensation process.

Due to the use of heated and pressed tees, the tonnage of equipment required for material forming is reduced. Hot pressed tees have a wide range of adaptability to materials, suitable for low carbon steel, alloy steel, and stainless steel materials; Especially for tees with large diameters and thick pipe walls, this forming process is commonly used.



Divided by material

Carbon steel, cast steel, alloy steel, stainless steel, copper, aluminum alloy, plastic, argon carbide, PVC, etc.

Divided by production method

Topping, pressing, forging, casting, etc.

Divided by manufacturing standards

GB/T12459-2017, ASME B16.9, SH3408, SH3409-96, SH3410-96, HG/T21635, DL/T 695, SY/T 0510, DIN 2615.

Astm A420 14inch S100 Alloy Steel Fittings Seamless Forged Butt Welded Pipe 0
Astm A420 14inch S100 Alloy Steel Fittings Seamless Forged Butt Welded Pipe 1

Product Description:

1. Material:Alloy Steel Tee

2. Size range: FROM 1/2" TO 72"

3. Pressure: Sch5--Sch160,XXS

4. STANDARDS ANSI, ISO, JIS, DIN, BS, GB, SH, HG, QOST, ETC.

5. CE and certification: ISO9001:2000, API, BV, SGS, LOIYD

6. Applications range: "Petroleum, chemical, power, gas, metallurgy, shipbuilding, construction, water and nuclear power etc.”

STANDARD

ASME/ANSI B16.9, B16.11, B16.28, JIS B2311, B2312, B2312, B2316

ASTM A403 MSS SP-43, SP-83, SP-97

MODEL 1.Tee (Straight and Reducing)
2.180 DEG Return
3.Elbow (45/90/180 DEG)
4.Cap
5. Reducer (Concentric and Eccentric)
TYPE Seam Or Seamless
ELBOW DEGREE 45 degree, 90 degree, 180 degree
SURFACE Black Paint, Anti Rust Oil, Hot-Dipped Galvanize
WALL THICKNESS SCH5S, SCH10S, SCH10, SCH20, SCH30, SCH40, STD, XS, SCH60
SCH80, SCH100, SCH120, SCH140, SCH160, XXS, 2MM
SIZE 1/2"-48"(Dn15-Dn1200)
CONNECTION Welding
SHAPE Equal, Reducing
CERTIFICATE ISO9001 API TUV
APPLICATION Petrochemical & Gas industry, Power industry, Valve industry, Water works, Shipbuilding industry, Construction etc



Astm A420 14inch S100 Alloy Steel Fittings Seamless Forged Butt Welded Pipe 2

Astm A420 14inch S100 Alloy Steel Fittings Seamless Forged Butt Welded Pipe 3

Chemical Composition:

Chemical Composition of ASTM A234

Element

WP5

WP9

WP11

WP91

C

Max 0.15

Max .15

0.05 - 0.15

0.08 - 0.12

Mn

0.30 - 0.60

0.30 - 0.60

0.30 - 0.60

0.30 - 0.60

P

Max 0.040

Max 0.030

Max 0.030

Max 0.020

S

Max 0.030

Max 0.030

Max 0.030

Max 0.010

Si

Max 0.50

0.25 - 1.00

0.50 - 1.00

0.20 - 0.50

Ni

-

-

-

Max 0.40

Cr

4.0 - 6.0

8.0 - 10.0

1.00 - 1.50

8.0 - 9.5

Mo

0.44 - 0.65

0.90 - 1.10

0.44 - 0.65

0.85 - 1.05

Cu

-

-

-

-

Cb

-

-

-

0.060 - 0.10

V

-

-

-

0.18 - 0.25

Astm A420 14inch S100 Alloy Steel Fittings Seamless Forged Butt Welded Pipe 4





Astm A420 14inch S100 Alloy Steel Fittings Seamless Forged Butt Welded Pipe 5

Astm A420 14inch S100 Alloy Steel Fittings Seamless Forged Butt Welded Pipe 6

Astm A420 14inch S100 Alloy Steel Fittings Seamless Forged Butt Welded Pipe 7



FAQ

Q. How long can make delivery?

A:For stock products, will make shipments in 5- 7 days after receiving deposit or receiving L/C; for products need new production for common materials, usually make shipments in 15-20 days; for products need new production for special and rare materials, usually need 30-40 days to make shipment.



Q:Can you provide the samples?



A:Samples can be provided with samples charge and courier fee by the buyer's side.



Q:Are the products in stock?



A:Yes.Most of our products are in stock.So we can prompt delivery.



Q:Can you accept customize?



A:Yes.It can be customized as per the customers' request.



Q:What about the quality?



A:According to the standard for production.And we can also accept the third-party
