Astm A335 Asme Sa335 Alloy Steel Seamless Tube Gr P22 14 "Sch100
Astm A335 Asme Sa335 Alloy Steel Seamless Tube Gr P22 14 "Sch100
Astm A335 Asme Sa335 Alloy Steel Seamless Tube Gr P22 14 "Sch100 Astm A335 Asme Sa335 Alloy Steel Seamless Tube Gr P22 14 "Sch100

Astm A335 Asme Sa335 Alloy Steel Seamless Tube Gr P22 14 "Sch100

Product Details:
Place of Origin: China
Brand Name: HongCheng
Certification: PED、ABS、BV、DNV、GL、LR、SGS、IEI
Model Number: 6/38”
Payment & Shipping Terms:
Minimum Order Quantity: 0.5Ton
Price: Negotiable
Packaging Details: Standard export seaworthy package,or as required
Delivery Time: 5-15 work days
Payment Terms: L/C, D/P, T/T
Supply Ability: 8000MT/Month
Contact Now
  • Detail Information
  • Product Description

Detail Information
Standards: JIS AISI ASTM GB DIN CE Section Shape: Round
Graded: A335 P11, A335 P5, A335 P91, A335 P9, A335 P1, A335 P12, A335 P92, A335 P23, 15crmo, 10CRMO910, Cr5Mo, 12CrMo, Cr9Mo, 12cr1movg, 15CrMoG, A53-A369, Cr-Mo Alloy Outside Diameter: Diameter 10.3 To 1219 Mm
Packaging Details: Ply-wooden Case /Iron Case/ Bundle With Plastic Cap Surface: Black Painted,PE Coated,Galvanized.
High Light:

Asme Sa335 alloy steel seamless tube

,

Alloy Steel Seamless Tube Sch100

,

Asme Sa335 alloy steel pipes tubes

Product Description

High quality steel Astm A335/Asme Sa335 alloy steel pipe Gr P22 14 "Sch100

The materials of alloy steel pipes can be divided into 12-42CrMo, T91, 30CrMo, 20G, 15CrMoV, Cr9Mo, 27SiMn, 10CrMo910, 15Mo3, 35CrMoV, 45CrMo, 15CrMoG, 12CrMoV, 45Cr, 16Mn12Cr1MoV, 50Cr, 15CrMo, 45CrNiMo, etc. according to the thickness and specification. Alloy steel pipe is made of carbon steel, stainless heat resistant steel and alloy structural steel by cold rolling technology or hot rolling technology.

Alloy steel pipe is lighter, and has greater advantages than solid materials such as round steel under the condition of consistent bending and torsional strength. In addition, alloy steel pipes are often used as pipes to transport fluids such as oil and gas. Because it has a unique hollow section. Alloy steel pipes are mainly used in nuclear power plants, power plants, high-pressure and high-temperature pipelines, and high-pressure boiler equipment.

A335 P9 Alloy Steel Pipe ASTM A335/ASME SA335 Gr. P5, P9, P11, P22, P91

Standard: ASTM A335

grade:P1, P2,P5,P9,P11,P91,P92

OD:10.3-660mm

WT:1.6-60mm

Length:5.8m-12m or random legth

Technical: Quenching & Tempering

Application: Gas fire power plant, coal fire power plant, headers and steam lines, Feed water pipes,

super heaters and reheaters.

A335 P9 Alloy Steel Pipe that covers “chrome-moly” seamless pipes with remarkable resistance to

corrosion and good tensile strength at high-temperature service. Generally, ASTM A335 P11, P22,

and P91 pipes are used in power generation and in downstream oil and gas, P5 and P9 grades are

for refinery applications.

How to define alloy pipes?



1.Chemical details:

Item C Si Mn P S Cr Mo
P1 0.10-0.20 0.10-0.50 0.3-0.80 ≤0.025 ≤0.025 / 0.44-0.65
P2 0.10-0.20 0.10-0.30 0.3-0.61 ≤0.025 ≤0.025 0.5-0.81 0.44-0.65
P5 ≤0.15 ≤0.50 0.3-0.60 ≤0.025 ≤0.025 4.0-6.0 0.44-0.65
P9 ≤0.15 ≤0.50 0.3-0.60 ≤0.030 ≤0.030 8.0-10.0 0.90-1.10
P11 0.05-0.15 0.5-1.0 0.3-0.60 ≤0.025 ≤0.025 1.0-1.50 0.44-0.65
P22 0.05-0.15 ≤0.50 0.3-0.60 ≤0.025 ≤0.025 1.9-2.60 0.87-1.13
P21 0.05-0.15 ≤0.50 0.3-0.60 ≤0.025 ≤0.025 2.65-3.35 0.80-1.06
P91 0.08-0.12 0.20-0.50 0.30-0.60 ≤0.020 ≤0.010 8.0-9.5 0.85-1.05
P15 0.05-0.15 1.15-1.65 0.30-0.60 ≤0.025 ≤0.025 / 0.44-0.65






Astm A335 Asme Sa335 Alloy Steel Seamless Tube Gr P22 14 "Sch100 0

1.Product details:

Item

Seamless pipe,seamless tube,seamless steel pipe,
seamless steel tube,seamless tubing
Standard ASTM,JIS,DIN,EN,GB,KS,API 5L,SUS,AISI
Material Stainless:310S,309S,310,309,316,316L,317,317L,321,321H,347,347H,304,304L,301,201,202,904L,Duplex,etc

Carbon steel:20#,20G,STPT410,STF410,A106 GR.B,A178C,A178D,P265GH,A53 GR.B,A135 GR.B,P265TR1,
P265TR2,STPT480,A106 GR.C,A210C,Q195,Q235,Q345,ST35.8,ST45.8,ST52, etc

Alloy:16Mn,Q345B,T1,T2,T5,T9,T11,T12,T22,T91,T92,P1,P2,P5,P9,P11,P12,P22,P91,P92,15CrMO,
Cr5Mo,10CrMo910,12CrMo,13CrMo44,30CrMo,A333 GR.1,GR.3,GR.6,GR.7,etc
API:Gr.B,X42,X46,X52,X60,X65,X70,X80,X100,etc

AISI:1010,1015,1020,1022,1025,1026,1030,1033,1035,1039,1040,1045,1050,1053,1060,3140,4130,4140,4142,
4118,4120,5115,5140,5150,etc


Size

 OD:6-2500mm
WT:SCH5-SCH160,XS,STD,XXS ,1-200mm
Length:5.8m,6m,11.8m,12m,or as required
Surface Black painted,PE coated,Galvanized,Varnished,HDPE,3PE,etc
Package Standard export package,suit for all kinds of transport, or as required
Export to

Singapore,Poland,India,Dubai,Korea,Thailand,Ukraine,USA,UK,Canada,Indonesia,Iraq,Mexico,Holland,South Africa,
Peru,Spain,Pakistan,Viet Nam,Saudi Arabia,Ireland,Jordan,Oman,Kuwait,Italy,Nigeria,Australia,etc

Container
Size

20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)
Payment term TT,L/C,Western Union,D/P,etc
Price term Ex-Work,FOB,CNF,CFR,CIF,FCA,DDP,DDU,etc
MOQ 1 Metric ton
Application

Seamless pipe are widely Used for the transmission fluid pipe, such as transport oil, natural gas,
coal gas, water and some solid pipeline etc
Contact

If you have any question,please feel free to contact me .
we are sure your inquiry or requirements will get prompt attention.




Astm A335 Asme Sa335 Alloy Steel Seamless Tube Gr P22 14 "Sch100 1



 Astm A335 Asme Sa335 Alloy Steel Seamless Tube Gr P22 14 "Sch100 2



Astm A335 Asme Sa335 Alloy Steel Seamless Tube Gr P22 14 "Sch100 3

FAQ

Q: Can you accept a trial order only for several tons?

A: We can ship the regular specifications with LCL service.

Q: Do you provide free samples?

A: Yes, we could offer the sample for free, with the cost of freight paid by customer.

Q: How long is your delivery time?

A: Generally it is 7-10 days if goods are in stock or as your order requirement.

Q:How can you guarantee what I got will be good ?

A: We are factory with 100% pre delivery inspection which guarantee the quality.

Q: What is your terms of payment?

A: Payment<=8000USD, 100% in advance.

Payment>=8000USD, 30% T/T in advance ,balance before shippment. Or L/C at sight (For big order, LC at 30-90days can be acceptable)
