Hebei Hongcheng Pipe Fittings Co., Ltd.

Astm A213 T91 T92 Sch40 Seamless Alloy Steel Pipe Low Temperature

Product Details:
Place of Origin: China
Brand Name: HongCheng
Certification: PED、ABS、BV、DNV、GL、LR、SGS、IEI
Model Number: 3" TO 14"
Payment & Shipping Terms:
Minimum Order Quantity: 1Ton
Price: Negotiable
Packaging Details: Standard export seaworthy package,or as required
Delivery Time: 7-15 work days
Payment Terms: L/C, D/P, T/T
Supply Ability: 2 Million Ton/Year
  • Detail Information
  • Product Description

Detail Information

Standards: API, ASTM, Bs, DIN, GB, JIS, API 5CT, API 5L, ASTM A106-2006, ASTM A53-2007, ASTM A335-2006, ASTM A213M-2001, BS 1387, BS EN 39, DIN 2391, DIN 17175, GB/T 3091-2001, GB/T8162, Gb/t8163, JIS G3444-2006, JIS G3441 Pressure: Sch30 Sch40 STD Sch60 Sch80 XS Sch100 Sch160
Export Tosia,Spain,South Africa, Vier Nam,Peru,Dubai,etc.: Singapore,Indonesia,Ukraine,Brazil,Korea,Thailand,USA, UK,Canada,Saudi Arabia,Ireland,Oman,Rus Certification: ABS, BV, DNV, GL, LR, SGS, IEI
Graded: A335 P11, A335 P5, A335 P91, A335 P9, A335 P1, A335 P12, A335 P92, A335 P23, 15crmo, 10CRMO910, Cr5Mo, 12CrMo, Cr9Mo, 12cr1movg, 15CrMoG, A53-A369, Cr-Mo Alloy Supply Ability :: 10000 PC Per Month
Grade: 20#, St37, A53(A, B), Q235
High Light:

astm a213 seamless alloy steel pipe

,

low temperature seamless alloy steel pipe

,

t92 alloy steel seamless pipe

Product Description

ASTM A213 T91 T92 12" Sch40 Alloy Seamless Steel Tube Boiler Tube

Alloy Seamless Steel Astm A335 P92 High Pressure Boiler Pipes Astm A335 P92 Seamless Alloy Steel Pipe

ASTM A335 P92 is the part of ASTM A335, The pipe shall be suitable for bending, flanging, and similar forming operations, and for fusion welding. The steel material shall conform to chemical composition, tensile property, and hardness requirements.

ASTM A335 P92 high pressure semaless boiler pipe, The range of ASTM A335 P92 seamless alloy steel pipe sizes that may be examined by each method shall be subjected to the limitations in the scope of the respective practice.



Product name Material Standard Size(mm) Application





Low temperature tube

16MnDG

10MnDG

09DG

09Mn2VDG

06Ni3MoDG

ASTM A333



GB/T18984-2003

ASTM A333





OD:8-1240*

WT:1-200

Apply to - 45 ℃ ~ 195 ℃ low temperature pressure vessel and low temperature heat exchanger pipe





High-pressure boiler tube

20G

ASTMA106B

ASTMA210A

ST45.8-III

GB5310-1995

ASTM SA106

ASTM SA210

DIN17175-79





OD:8-1240*

WT:1-200



Suitable for manufacturing high pressure boiler tube, header, steam pipe, etc

Petroleum cracking tube



10

20



GB9948-2006



OD: 8-630*

WT:1-60

Used in oil refinery furnace tube, heat exchanger tube





Low medium pressure boiler tube





10#

20#

16Mn,Q345





GB3087-2008





OD:8-1240*

WT:1-200

Suitable for manufacturing various structure of low and medium pressure boiler and locomotive boiler





General structure

of the tube



10#,20#,45#,27SiMn

ASTM A53A,B

16Mn,Q345

GB/T8162-

2008

GB/T17396-

1998

ASTM A53





OD:8-1240*

WT:1-200

Apply to the general structure, engineering support, mechanical processing, etc





Oil casing



J55,K55,N80,L80

C90,C95,P110



API SPEC 5CT

ISO11960



OD:60-508*

WT:4.24-16.13

Used for extraction of oil or gas in oil Wells casing, used in oil and gas well sidewall



Astm A213 T91 T92 Sch40 Seamless Alloy Steel Pipe Low Temperature 0

1.Product details:

Item

Seamless pipe,seamless tube,seamless steel pipe,

seamless steel tube,seamless tubing

Standard ASTM,JIS,DIN,EN,GB,KS,API 5L,SUS,AISI
Material Stainless:310S,309S,310,309,316,316L,317,317L,321,321H,347,347H,304,304L,301,201,202,904L,Duplex,etc

Carbon steel:20#,20G,STPT410,STF410,A106 GR.B,A178C,A178D,P265GH,A53 GR.B,A135 GR.B,P265TR1,

P265TR2,STPT480,A106 GR.C,A210C,Q195,Q235,Q345,ST35.8,ST45.8,ST52, etc

Alloy:16Mn,Q345B,T1,T2,T5,T9,T11,T12,T22,T91,T92,P1,P2,P5,P9,P11,P12,P22,P91,P92,15CrMO,

Cr5Mo,10CrMo910,12CrMo,13CrMo44,30CrMo,A333 GR.1,GR.3,GR.6,GR.7,etc

API:Gr.B,X42,X46,X52,X60,X65,X70,X80,X100,etc

AISI:1010,1015,1020,1022,1025,1026,1030,1033,1035,1039,1040,1045,1050,1053,1060,3140,4130,4140,4142,

4118,4120,5115,5140,5150,etc



Size

OD:6-2500mm
WT:SCH5-SCH160,XS,STD,XXS ,1-200mm
Length:5.8m,6m,11.8m,12m,or as required
Surface Black painted,PE coated,Galvanized,Varnished,HDPE,3PE,etc
Package Standard export package,suit for all kinds of transport, or as required
Export to

Singapore,Poland,India,Dubai,Korea,Thailand,Ukraine,USA,UK,Canada,Indonesia,Iraq,Mexico,Holland,South Africa,

Peru,Spain,Pakistan,Viet Nam,Saudi Arabia,Ireland,Jordan,Oman,Kuwait,Italy,Nigeria,Australia,etc

Astm A213 T91 T92 Sch40 Seamless Alloy Steel Pipe Low Temperature 1



Mechanical Property:

Standard Grade Tensile Strength(MPa) Yield Strength(MPa) Elongation(%)
≤16 >16-30mm
GB/T8162-1999 10 335 205 195 24
20 390 245 235 20
35 510 305 295 17
45 590 335 325 14
16Mn 490 325 315 21
GB/T8163 10 335~475 ≥205 ≥24
20 410~550 ≥245 ≥20
Q345 490~665 ≥325 ≥21
GB/T3087 10 333-475 ≥196 ≥24
20 392-588 ≥245/226 ≥20
GB/T5310 20G 410-550 ≥245 ≥24
12CrMoG 410-560 ≥205 ≥21
15CrMoG 450-640 ≥235 ≥21
12Cr1MoVG 470-640 ≥255 ≥21
GB/T9948 10 330-490 ≥205 ≥24
20 410-550 ≥245 ≥21
12CrMoG 410-560 ≥205 ≥21
15CrMoG 410-640 ≥235 ≥21
GB/T6479 10 330-490 ≥205 ≥24
20 410-500 ≥245 ≥21
12CrMo 410-560 ≥205 ≥21
15CrMo 440-640 ≥235 ≥21

Astm A213 T91 T92 Sch40 Seamless Alloy Steel Pipe Low Temperature 2

standard the name of a shop tensile strength (MPa) Yield strength (MPa) (%) of elongation hardness
GB3087 10 335~475 ≥195 ≥24 /
20 410~550 ≥245 ≥20 /
GB5310 20G 410~550 ≥245 ≥24 /
20MnG ≥415 ≥240 ≥22 /
25MnG ≥485 ≥275 ≥20 /
15CrMoG 440~640 ≥235 ≥21 /
12Cr2MoG 450~600 ≥280 ≥20 /
12Cr1MoVG 470~640 ≥255 ≥21 /
12Cr2MoWVTiB 540~735 ≥345 ≥18 /
10Cr9Mo1VNb ≥585 ≥415 ≥20 /
ASME SA210 SA210A-1 ≥415 ≥255 ≥30 ≤143HB
SA210C ≥485 ≥275 ≥30 ≤179HB
ASME SA213 SA213 T11 ≥415 ≥205 ≥30 ≤163HB
SA213 T12 ≥415 ≥220 ≥30 ≤163HB
SA213 T22 ≥415 ≥205 ≥30 ≤163HB
SA213 T23 ≥510 ≥400 ≥20 ≤220HB
SA213 T91 ≥585 ≥415 ≥20 ≤250HB
SA213 T92 ≥620 ≥440 ≥20 ≤250HB
DIN17175 ST45.8/Ⅲ 410~530 ≥255 ≥21 /
  15Mo3 450~600 ≥270 ≥22
13CrMo44 440~590 ≥290 ≥22 /
10CrMo910 480~630 ≥280 ≥20

/









Astm A213 T91 T92 Sch40 Seamless Alloy Steel Pipe Low Temperature 3







FAQ



1.Q:Are you a factory or trading company?

A: We are a factory, has more than 20 years experience in pipe fittings production.

2.Q:Where is your factory located? How can I visit there?

A: Our factory is located in cangzhou City, hebei Province,China.

3.Q:How does your factory do regarding quality control?

A: We are ISO9001& PED certified by TUV. We serious control the quality from raw material to finished pipe fittings. So that we can 100% sure our goods is qualified.

4. Q: Price high ?

A: Our price is workable. We had tried use auto equipment to save Workers cost, and control other costs. like human sources, logistics etc.

5.Q: After sales service.

A: Quality are promised. If our products are not meet the contract we would like to send free goods to you.
