Product Details:
|
|
Place of Origin: | China |
---|---|
Brand Name: | HongCheng |
Certification: | PED、ABS、BV、DNV、GL、LR、SGS、IEI |
Model Number: | 6" TO 24" |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 1Ton |
Price: | Negotiable |
Packaging Details: | Standard export seaworthy package,or as required |
Delivery Time: | 7-15 work days |
Payment Terms: | L/C, D/P, T/T |
Supply Ability: | 2 Million Ton/Year |
Detail Information |
|||
Standards: | API, ASTM, Bs, DIN, GB, JIS, API 5CT, API 5L, ASTM A106-2006, ASTM A53-2007, ASTM A335-2006, ASTM A213M-2001, BS 1387, BS EN 39, DIN 2391, DIN 17175, GB/T 3091-2001, GB/T8162, Gb/t8163, JIS G3444-2006, JIS G3441 | Certification: | ABS, BV, DNV, GL, LR, SGS, IEI |
---|---|---|---|
Pressure: | Sch30 Sch40 STD Sch60 Sch80 XS Sch100 Sch160 | Graded: | A335 P11, A335 P5, A335 P91, A335 P9, A335 P1, A335 P12, A335 P92, A335 P23, 15crmo, 10CRMO910, Cr5Mo, 12CrMo, Cr9Mo, 12cr1movg, 15CrMoG, A53-A369, Cr-Mo Alloy |
Export Tosia,Spain,South Africa, Vier Nam,Peru,Dubai,etc.: | Singapore,Indonesia,Ukraine,Brazil,Korea,Thailand,USA, UK,Canada,Saudi Arabia,Ireland,Oman,Rus | Material: | Q195/Q215/Q235/Q345, ASTM A335 P91 Seamless Alloy Pipe, Carbon Steel &Alloy Steel, X42, Cast Iron |
High Light: | 24 inch alloy seamless steel pipe,api standards alloy seamless steel pipe,6 inch alloy steel seamless pipe |
Product Description
Alloy Seamless Steel Astm A335 P92 High Pressure Boiler Pipes Astm A335 P92 Seamless Alloy Steel Pipe
ASTM A335 P92 is the part of ASTM A335, The pipe shall be suitable for bending, flanging, and similar forming operations, and for fusion welding. The steel material shall conform to chemical composition, tensile property, and hardness requirements.
ASTM A335 P92 high pressure semaless boiler pipe, The range of ASTM A335 P92 seamless alloy steel pipe sizes that may be examined by each method shall be subjected to the limitations in the scope of the respective practice.
1.Product details:
Item |
Seamless pipe,seamless tube,seamless steel pipe, seamless steel tube,seamless tubing |
Standard | ASTM,JIS,DIN,EN,GB,KS,API 5L,SUS,AISI |
Material | Stainless:310S,309S,310,309,316,316L,317,317L,321,321H,347,347H,304,304L,301,201,202,904L,Duplex,etc |
Carbon steel:20#,20G,STPT410,STF410,A106 GR.B,A178C,A178D,P265GH,A53 GR.B,A135 GR.B,P265TR1, P265TR2,STPT480,A106 GR.C,A210C,Q195,Q235,Q345,ST35.8,ST45.8,ST52, etc |
|
Alloy:16Mn,Q345B,T1,T2,T5,T9,T11,T12,T22,T91,T92,P1,P2,P5,P9,P11,P12,P22,P91,P92,15CrMO, Cr5Mo,10CrMo910,12CrMo,13CrMo44,30CrMo,A333 GR.1,GR.3,GR.6,GR.7,etc |
|
API:Gr.B,X42,X46,X52,X60,X65,X70,X80,X100,etc | |
AISI:1010,1015,1020,1022,1025,1026,1030,1033,1035,1039,1040,1045,1050,1053,1060,3140,4130,4140,4142, 4118,4120,5115,5140,5150,etc |
|
Size |
OD:6-2500mm |
WT:SCH5-SCH160,XS,STD,XXS ,1-200mm | |
Length:5.8m,6m,11.8m,12m,or as required | |
Surface | Black painted,PE coated,Galvanized,Varnished,HDPE,3PE,etc |
Package | Standard export package,suit for all kinds of transport, or as required |
Export to |
Singapore,Poland,India,Dubai,Korea,Thailand,Ukraine,USA,UK,Canada,Indonesia,Iraq,Mexico,Holland,South Africa, Peru,Spain,Pakistan,Viet Nam,Saudi Arabia,Ireland,Jordan,Oman,Kuwait,Italy,Nigeria,Australia,etc |
2.Chemical details:
Item | C | Si | Mn | P | S | Cr | Mo |
P1 | 0.10-0.20 | 0.10-0.50 | 0.3-0.80 | ≤0.025 | ≤0.025 | / | 0.44-0.65 |
P2 | 0.10-0.20 | 0.10-0.30 | 0.3-0.61 | ≤0.025 | ≤0.025 | 0.5-0.81 | 0.44-0.65 |
P5 | ≤0.15 | ≤0.50 | 0.3-0.60 | ≤0.025 | ≤0.025 | 4.0-6.0 | 0.44-0.65 |
P9 | ≤0.15 | ≤0.50 | 0.3-0.60 | ≤0.030 | ≤0.030 | 8.0-10.0 | 0.90-1.10 |
P11 | 0.05-0.15 | 0.5-1.0 | 0.3-0.60 | ≤0.025 | ≤0.025 | 1.0-1.50 | 0.44-0.65 |
P22 | 0.05-0.15 | ≤0.50 | 0.3-0.60 | ≤0.025 | ≤0.025 | 1.9-2.60 | 0.87-1.13 |
P21 | 0.05-0.15 | ≤0.50 | 0.3-0.60 | ≤0.025 | ≤0.025 | 2.65-3.35 | 0.80-1.06 |
P91 | 0.08-0.12 | 0.20-0.50 | 0.30-0.60 | ≤0.020 | ≤0.010 | 8.0-9.5 | 0.85-1.05 |
P15 | 0.05-0.15 | 1.15-1.65 | 0.30-0.60 | ≤0.025 | ≤0.025 | / | 0.44-0.65 |
Mechanical Property:
Standard | Grade | Tensile Strength(MPa) | Yield Strength(MPa) | Elongation(%) | |
≤16 | >16-30mm | ||||
GB/T8162-1999 | 10 | 335 | 205 | 195 | 24 |
20 | 390 | 245 | 235 | 20 | |
35 | 510 | 305 | 295 | 17 | |
45 | 590 | 335 | 325 | 14 | |
16Mn | 490 | 325 | 315 | 21 | |
GB/T8163 | 10 | 335~475 | ≥205 | ≥24 | |
20 | 410~550 | ≥245 | ≥20 | ||
Q345 | 490~665 | ≥325 | ≥21 | ||
GB/T3087 | 10 | 333-475 | ≥196 | ≥24 | |
20 | 392-588 | ≥245/226 | ≥20 | ||
GB/T5310 | 20G | 410-550 | ≥245 | ≥24 | |
12CrMoG | 410-560 | ≥205 | ≥21 | ||
15CrMoG | 450-640 | ≥235 | ≥21 | ||
12Cr1MoVG | 470-640 | ≥255 | ≥21 | ||
GB/T9948 | 10 | 330-490 | ≥205 | ≥24 | |
20 | 410-550 | ≥245 | ≥21 | ||
12CrMoG | 410-560 | ≥205 | ≥21 | ||
15CrMoG | 410-640 | ≥235 | ≥21 | ||
GB/T6479 | 10 | 330-490 | ≥205 | ≥24 | |
20 | 410-500 | ≥245 | ≥21 | ||
12CrMo | 410-560 | ≥205 | ≥21 | ||
15CrMo | 440-640 | ≥235 | ≥21 |
