Hebei Hongcheng Pipe Fittings Co., Ltd.

Thick 10" Sch80 Alloy Seamless Pipe Tube Hot Rolled For Boiler

Product Details:
Place of Origin: China
Brand Name: HongCheng
Certification: PED、ABS、BV、DNV、GL、LR、SGS、IEI
Model Number: 6" TO 24"
Payment & Shipping Terms:
Minimum Order Quantity: 0.5Ton
Price: Negotiable
Packaging Details: Standard export seaworthy package,or as required
Delivery Time: 7-15 work days
Payment Terms: L/C, D/P, T/T
Supply Ability: 2 Million Ton/Year
  • Detail Information
  • Product Description

Detail Information

Standard: Alloy Steel Seamless Pipe, Alloy Steel Pipe Gr P5, Alloy Steel Pipe Gr P11, Alloy Steel Pipe Gr P9, Alloy Steel Pipe Gr P22, Alloy Steel Pipe Gr P91, ASTM A335, Standards: API, ASTM, Bs, DIN, GB, JIS, API 5CT, API 5L, ASTM A106-2006, ASTM A53-2007, ASTM A335-2006, ASTM A213M-2001, BS 1387, BS EN 39, DIN 2391, DIN 17175, GB/T 3091-2001, GB/T8162, Gb/t8163, JIS G3444-2006, JIS G3441
Certification: ABS, BV, DNV, GL, LR, SGS, IEI Export Tosia,Spain,South Africa, Vier Nam,Peru,Dubai,etc.: Singapore,Indonesia,Ukraine,Brazil,Korea,Thailand,USA, UK,Canada,Saudi Arabia,Ireland,Oman,Rus
Port: Tianjin Performance: Welding, Punching, Cutting, Bending,
Pressure: Sch30 Sch40 STD Sch60 Sch80 XS Sch100 Sch160 Graded: A335 P11, A335 P5, A335 P91, A335 P9, A335 P1, A335 P12, A335 P92, A335 P23, 15crmo, 10CRMO910, Cr5Mo, 12CrMo, Cr9Mo, 12cr1movg, 15CrMoG, A53-A369, Cr-Mo Alloy
High Light:

10" alloy seamless pipe

,

sch80 alloy seamless pipe

,

hot rolled boiler seamless alloy tube

Product Description

Thick 10" 12” Sch80  Sch120 Alloy Seamless Steel Tube Hot Rolled For Boiler

Alloy steel pipe applies to petroleum,chemical industry, electric power, boiler, high temperature resistant, low temperature resistant,corrosion resistant seamless steel pipe used.Alloy steel pipealso can made according to the customer.



Container size

20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 24-26CBM



40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 54CBM



40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) 68CBM



Outer Dimensions: 19.05mm – 114.3mm

Wall Thickness: 2.0mm – 14 mm

Length: max 16000mm

Steel grade: ASTM A335 P92

Packing:

Bare packing/bundle packing/crate packing/wooden protection at the both sides of tubes and suitably protected for sea-worthly delivery or as requested.

Inspection and Test:

Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength,Yield Strength, Elongation, Flaring, Flattening, Bending, Hardness, Impact Test), Surface and Dimension Test,No-destructive Test, Hydrostatic Test.

Surface treatment:

Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting.

Both ends of each crate will indicate the order no., heat no., dimensions, weight and bundles or as requested.

Chemical Requirements of ASTM A335 P92



UNS Designation

K92460

Carbon

0.07–0.13

Manganese

0.30–0.60

Phosphorus(max)

0.02

Sulfur(max)

0.01

Silicon

0.50 max

Chromium

8.50–9.50

Molybdenum

0.30–0.60

V

0.15-0.25

N

0.03-0.07

Ni (max)

0.4

Al(max)

0.02

Cb

0.04-0.09

W

1.5-2.00

B

0.001-0.006

Ti (max)

0.01

Zr(max)

0.01

Mechanical Properties of ASTM A335 P92



Properties

Data

Tensile strength, min, (MPa)

620

Yield strength, min, (MPa)

440

Elongation, min, (%), L/T

20/…

Material & Manufacture

Pipe may be either hot finished or cold drawn with the finishing heat treatment noted below.

Heat Treatment

A / N+T

N+T / Q+T

N+T

Mechanical Tests Specified

Transverse or Longitudinal Tension Test and Flattening Test, Hardness Test, or Bend Test

For material heat treated in a batch-type furnace, tests shall be made on 5% of the pipe from each treated lot. For small lots, at least one pipe shall be tested.

For material heat treated by the continuous process, tests shall be made on a sufficient number of pipe to constitute 5% of the lot, but in no case less than 2 pipe.

Notes for Bend Test:

For pipe whose diameter exceeds NPS 25 and whose diameter to wall thickness ratio is 7.0 or less shall be subjected to the bend test instead of the flattening test.

Other pipe whose diameter equals or exceeds NPS 10 may be given the bend test in place of the flattening test subject to the approval of the purchaser.

The bend test specimens shall be bent at room temperature through 180 without cracking on the outside of the bent portion.



Thick 10" Sch80 Alloy Seamless Pipe Tube Hot Rolled For Boiler 0

1.Product details:

Item

Seamless pipe,seamless tube,seamless steel pipe,

seamless steel tube,seamless tubing

Standard

ASTM,JIS,DIN,EN,GB,KS,API 5L,SUS,AISI

Material

Stainless:310S,309S,310,309,316,316L,317,317L,321,321H,347,347H,304,304L,301,201,202,904L,Duplex,etc

Carbon steel:20#,20G,STPT410,STF410,A106 GR.B,A178C,A178D,P265GH,A53 GR.B,A135 GR.B,P265TR1,

P265TR2,STPT480,A106 GR.C,A210C,Q195,Q235,Q345,ST35.8,ST45.8,ST52, etc

Alloy:16Mn,Q345B,T1,T2,T5,T9,T11,T12,T22,T91,T92,P1,P2,P5,P9,P11,P12,P22,P91,P92,15CrMO,

Cr5Mo,10CrMo910,12CrMo,13CrMo44,30CrMo,A333 GR.1,GR.3,GR.6,GR.7,etc

API:Gr.B,X42,X46,X52,X60,X65,X70,X80,X100,etc

AISI:1010,1015,1020,1022,1025,1026,1030,1033,1035,1039,1040,1045,1050,1053,1060,3140,4130,4140,4142,

4118,4120,5115,5140,5150,etc



Size

OD:6-2500mm

WT:SCH5-SCH160,XS,STD,XXS ,1-200mm

Length:5.8m,6m,11.8m,12m,or as required

Surface

Black painted,PE coated,Galvanized,Varnished,HDPE,3PE,etc

Package

Standard export package,suit for all kinds of transport, or as required

Export to

Singapore,Poland,India,Dubai,Korea,Thailand,Ukraine,USA,UK,Canada,Indonesia,Iraq,Mexico,Holland,South Africa,

Peru,Spain,Pakistan,Viet Nam,Saudi Arabia,Ireland,Jordan,Oman,Kuwait,Italy,Nigeria,Australia,etc

Container

Size

20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)

40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)

40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)

Payment term

TT,L/C,Western Union,D/P,etc

Price term

Ex-Work,FOB,CNF,CFR,CIF,FCA,DDP,DDU,etc

MOQ

1 Metric ton

Application

Seamless pipe are widely Used for the transmission fluid pipe, such as transport oil, natural gas,

coal gas, water and some solid pipeline etc

Contact

If you have any question,please feel free to contact me .

we are sure your inquiry or requirements will get prompt attention.



Thick 10" Sch80 Alloy Seamless Pipe Tube Hot Rolled For Boiler 1
seamless steel pipe chemical composition:

Grade

C

Si

Mn

P

S

Cr

Mo

P5

Max.0.15

Max.0.50

0.3-0.6

Max.0.025

Max.0.025

4--6

0.45-0.65

P11

0.05-0.15

0.5-1.0

0.3-0.6

Max.0.025

Max.0.025

1.0-1.5

0.44-0.65

P12

0.05-0.15

Max.0.50

0.3-0.61

Max.0.025

Max.0.025

0.8-1.25

0.44-0.65

P22

0.05-0.15

Max.0.50

0.3-0.6

Max.0.025

Max.0.025

1.9-2.6

0.87-1.13

Mechanical properties















Grade

Yield point (Mpa)

Tensile strength (Mpa)

Elongation(%)

Impact value(J)







P5

≥205

≥415

See table

≥35







P11

≥205

≥415

See table

≥35







P12

≥220

≥415

See table

≥35







P22

≥205

≥415

See table

≥35





















Thick 10" Sch80 Alloy Seamless Pipe Tube Hot Rolled For Boiler 2







FAQ



1.Q:Are you a factory or trading company?

A: We are a factory, has more than 20 years experience in pipe fittings production.

2.Q:Where is your factory located? How can I visit there?

A: Our factory is located in cangzhou City, hebei Province,China.

3.Q:How does your factory do regarding quality control?

A: We are ISO9001& PED certified by TUV. We serious control the quality from raw material to finished pipe fittings. So that we can 100% sure our goods is qualified.

4. Q: Price high ?

A: Our price is workable. We had tried use auto equipment to save Workers cost, and control other costs. like human sources, logistics etc.

5.Q: After sales service.

A: Quality are promised. If our products are not meet the contract we would like to send free goods to you.
