Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | HongCheng |
| Certification: | PED、ABS、BV、DNV、GL、LR、SGS、IEI |
| Model Number: | 1/2" TO 28" |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 0.5Ton |
| Price: | Negotiable |
| Packaging Details: | Standard export seaworthy package,or as required |
| Delivery Time: | 7-15 work days |
| Payment Terms: | L/C, D/P, T/T, MoneyGram |
| Supply Ability: | 2 Million Ton/Year |
|
Detail Information |
|||
| Material: | P1, P2, P12, P11, P22, P5, P9, P91, P92,T1, T2, T11,T12, T5, T9, T22, ST52, X42, X46,X52,X60,X70,X80,X100,15CrMo,Cr5Mo,10CrMo910,12Cr2Mo,13CrMo44,12CrMo195,42CrMo,42CrMO4, X12CrMo91,12CrMo,etc | Pressure: | Sch30 Sch40 STD Sch60 Sch80 XS Sch100 Sch160 |
|---|---|---|---|
| Standards: | API, ASTM, Bs, DIN, GB, JIS, API 5CT, API 5L, ASTM A106-2006, ASTM A53-2007, ASTM A335-2006, ASTM A213M-2001, BS 1387, BS EN 39, DIN 2391, DIN 17175, GB/T 3091-2001, GB/T8162, Gb/t8163, JIS G3444-2006, JIS G3441 | Standard: | Alloy Steel Seamless Pipe, Alloy Steel Pipe Gr P5, Alloy Steel Pipe Gr P11, Alloy Steel Pipe Gr P9, Alloy Steel Pipe Gr P22, Alloy Steel Pipe Gr P91, ASTM A335, |
| Application: | Alloy Steel Pipe Applies To Petroleum, Chemical Industry, Electric Power, Boiler, High Temperature Resistant, Low Temperature Resistant, Corrosion Resistant Part. The Size Of Alloy Steel Pipe Can Be Made According To The Customers Requirements. | Export Tosia,Spain,South Africa, Vier Nam,Peru,Dubai,etc.: | Singapore,Indonesia,Ukraine,Brazil,Korea,Thailand,USA, UK,Canada,Saudi Arabia,Ireland,Oman,Rus |
| Port：: | Tianjin | Variety: | Equal Diameter Reducing Tee |
| High Light: | wp5 alloy seamless steel pipe,alloy seamless steel pipe hot rolled,wp11 alloy steel seamless pipe |
||
Product Description
| Product name | Material | Standard | Size(mm) | Application |
|
Low temperature tube |
16MnDG 10MnDG 09DG 09Mn2VDG 06Ni3MoDG ASTM A333 |
GB/T18984-2003 ASTM A333 |
OD:8-1240* WT:1-200 |
Apply to - 45 ℃ ~ 195 ℃ low temperature pressure vessel and low temperature heat exchanger pipe |
|
High-pressure boiler tube |
20G ASTMA106B ASTMA210A ST45.8-III |
GB5310-1995 ASTM SA106 ASTM SA210 DIN17175-79 |
OD:8-1240* WT:1-200 |
Suitable for manufacturing high pressure boiler tube, header, steam pipe, etc |
| Petroleum cracking tube |
10 20 |
GB9948-2006 |
OD: 8-630* WT:1-60 |
Used in oil refinery furnace tube, heat exchanger tube |
|
Low medium pressure boiler tube |
10# 20# 16Mn,Q345 |
GB3087-2008 |
OD:8-1240* WT:1-200 |
Suitable for manufacturing various structure of low and medium pressure boiler and locomotive boiler |
|
General structure of the tube |
10#,20#,45#,27SiMn ASTM A53A,B 16Mn,Q345 |
GB/T8162- 2008 GB/T17396- 1998 ASTM A53 |
OD:8-1240* WT:1-200 |
Apply to the general structure, engineering support, mechanical processing, etc |
|
Oil casing |
J55,K55,N80,L80 C90,C95,P110 |
API SPEC 5CT ISO11960 |
OD:60-508* WT:4.24-16.13 |
Used for extraction of oil or gas in oil Wells casing, used in oil and gas well sidewall |
Mechanical Property:
| Standard | Grade | Tensile Strength(MPa) | Yield Strength(MPa) | Elongation(%) | |
| ≤16 | >16-30mm | ||||
| GB/T8162-1999 | 10 | 335 | 205 | 195 | 24 |
| 20 | 390 | 245 | 235 | 20 | |
| 35 | 510 | 305 | 295 | 17 | |
| 45 | 590 | 335 | 325 | 14 | |
| 16Mn | 490 | 325 | 315 | 21 | |
| GB/T8163 | 10 | 335~475 | ≥205 | ≥24 | |
| 20 | 410~550 | ≥245 | ≥20 | ||
| Q345 | 490~665 | ≥325 | ≥21 | ||
| GB/T3087 | 10 | 333-475 | ≥196 | ≥24 | |
| 20 | 392-588 | ≥245/226 | ≥20 | ||
| GB/T5310 | 20G | 410-550 | ≥245 | ≥24 | |
| 12CrMoG | 410-560 | ≥205 | ≥21 | ||
| 15CrMoG | 450-640 | ≥235 | ≥21 | ||
| 12Cr1MoVG | 470-640 | ≥255 | ≥21 | ||
| GB/T9948 | 10 | 330-490 | ≥205 | ≥24 | |
| 20 | 410-550 | ≥245 | ≥21 | ||
| 12CrMoG | 410-560 | ≥205 | ≥21 | ||
| 15CrMoG | 410-640 | ≥235 | ≥21 | ||
| GB/T6479 | 10 | 330-490 | ≥205 | ≥24 | |
| 20 | 410-500 | ≥245 | ≥21 | ||
| 12CrMo | 410-560 | ≥205 | ≥21 | ||
| 15CrMo | 440-640 | ≥235 | ≥21 | ||
