Xxs Std Alloy Seamless Steel Pipe 1/2 Inch Quenching Tempering

Product Description

Thick Wall Alloy Hot Rolled Seamless Steel Tu P22 12" 14" 16" 18" 20" Sch40 Sch60 Sch80 Xxs Std



A335 P9 Alloy Steel Pipe ASTM A335/ASME SA335 Gr. P5, P9, P11, P22, P91

Standard: ASTM A335

grade:P1, P2,P5,P9,P11,P91,P92

OD:10.3-660mm

WT:1.6-60mm

Length:5.8m-12m or random legth

Technical: Quenching & Tempering

Application: Gas fire power plant, coal fire power plant, headers and steam lines, Feed water pipes,

super heaters and reheaters.

A335 P9 Alloy Steel Pipe that covers “chrome-moly” seamless pipes with remarkable resistance to

corrosion and good tensile strength at high-temperature service. Generally, ASTM A335 P11, P22,

and P91 pipes are used in power generation and in downstream oil and gas, P5 and P9 grades are

for refinery applications.

How to define alloy pipes?

Alloy pipes are tubular with higher percentages, than standard carbon steel pipes, of alloying elements

as Molybdenum (Mo), Chromium (Cr), Nickel, etc. Actually, the ASTM A335 covers “low-alloy” steel pipes,

i.e. pipes that have a total amount of alloying elements below 5%. The addition of higher percentages of

alloying elements (example Nickel and Chromium) transforms the steel into higher alloys, like stainless steel,

duplex, up to super-alloyed materials like Inconel, Hastelloy, Monel, etc.

Alloy steel pipes are used in the energy industry for high temperature and very low-temperature service

(cryogenic), or for applications with very high pressures.

ASTM A335 alloy steel pipes fit ASTM A234 WPx series buttweld fittings (WP5, WP9, WP91) and A182 Fx

forged fittings and flanges (A182 F5, F9, F11, F22, F91). All these materials have similar chemical and mechanical

properties and can be joined or welded.

Alloying elements

The addition of Molybdenum (“Moly”) increases the strength of the steel and its elastic limit, enhance

the steel resistance to wear, its impact qualities, and the hardenability. It also improves the resistance

to softening, makes chromium steel less prone to embrittlement and prevents pitting.

Chromium, a key element also for stainless steel alloys, prevents steel oxidation at elevated temperatures

and increases the resistance of steel to corrosion. It enhances the tensile, yield, and hardness properties

of low-alloy pipes at room temperatures.

Other alloying elements, present in various degrees in pipes of all grades are:

1. Aluminum: decreases oxygen from steelmaking

2. Boron: used to produce fine grain size and enhance steel hardness

3. Cobalt: used to enhance the steel’s heat and wear-resistance

4. Manganese: gives better steel hardenability

5. Nickel: Enhances toughness, hardenability and impact strength at low temperatures

6. Silicon: decreases oxygen, enhances hardenability and toughness

7. Titanium: prevents precipitation of chromium carbide

8. Tungsten: refines steel grain size and enhance the steel hardness, especially at high temperatures

9. Vanadium: gives steel enhanced fatigue resistance



ASTM A335 P91 Seamless Ferritic Alloy-Steel Pipe for High-Temperature Service



WE SPECIALIZED IN PRODUCING AND EXPORTING CARBON STEEL SEAMLESS PIPES AND WELDED STEEL PIPES, BLACK AND HOT-DIPPED GALVANZIED, MEDIUM AND LOW PRESSURE BOILER TUBES, OIL CASING TUBING AND LINE PIPES, QUALIFY THE INTERNATIONAL STANDARD, SUCH AS API 5CT J55/55/N80/P110, API 5L/ASTM A53/A106 GRADE A/B, ASME A179/A192, DIN 2440/2448, BS1387, etc. SIZES AVAILABLE IN RANGE: 1/4"-48".

astm a335 p91 seamless pipe manufactuer ,p91 seamless steel pipe exporter, p91 seamless black pipes stockholder ,black seamless alloy pipe supplier in china

ASTM A335 Steel Ferritic Alloy Tubes Pipe for High-Temperature and Boilers

ASTM A335 Seamless ferritic and alloy steel pipe for high temperature service

Applications: for Boilers,Superheaters,Heat-Exchangers

Size range: O.D.:6-420mm W.T.:1-50mm L: according to customer requirement



Production details:

Standard	ASTM, BS, JIS, DIN,GB
O.D.	1/2"-24" 10-610mm
W.T.	SCH10--XXS 1.5-60mm
Length	5m-12m
End protection	Plastic caps
Outside Coating	Black painting, anti-corrosion oil, galvanized or as per required by customers
Packing	Wrapped in bundles by steel strips/bulk
Delivery	By sea container
Production Capacity	5000 tons per month
Delivery time	10-30days depend on your quantity
Tolorance	OD :+1% / -1% WT: +12.5% / -10%
Application	Transportation of oil,gas or fluid,Construction,Electricity,Machine building industy,Chemical industy,Petroleum,Traffic.
Main market	Asia, India, Middle East, America, Europe

seamless steel pipe chemical composition:

Grade	C	Si	Mn	P	S	Cr	Mo
P5	Max.0.15	Max.0.50	0.3-0.6	Max.0.025	Max.0.025	4--6	0.45-0.65
P11	0.05-0.15	0.5-1.0	0.3-0.6	Max.0.025	Max.0.025	1.0-1.5	0.44-0.65
P12	0.05-0.15	Max.0.50	0.3-0.61	Max.0.025	Max.0.025	0.8-1.25	0.44-0.65
P22	0.05-0.15	Max.0.50	0.3-0.6	Max.0.025	Max.0.025	1.9-2.6	0.87-1.13
Mechanical properties
Grade	Yield point (Mpa)	Tensile strength (Mpa)	Elongation(%)	Impact value(J)
P5	≥205	≥415	See table	≥35
P11	≥205	≥415	See table	≥35
P12	≥220	≥415	See table	≥35
P22	≥205	≥415	See table	≥35

about us:

Hebei Hongcheng Pipe Industry Co., Ltd. was established in 1992 and is located in the Development Zone of Yanshan County, Hebei Province. We are one of the largest steel product manufacturers on the coast of the Bohai Sea. A three-dimensional comprehensive transportation network has been formed. Our geographical position is superior and the transportation is very convenient.

We are one of the biggest manufacturer for steel products with a 80, 000-square-meter workshop,covers an area more than 120,000 square meters in size ,and well over 50 million USD in assets.our main products including stainless steel pipe ,stainless steel plate,stainless steel bar,seamless steel pipe ,low temperature steel pipe ,alloy steel pipe ,boiler pipe ,carbon steel plate ,alloy steel plate ,pipe fitting,copper products,titanium products and nickel products.our company has the most advanced production equipment which guarantee the most advantageous product quality.Based on highly quality products and best service,we have develop clients all round the world ,our products are widely used in industry in USA ,Germany ,India ,Dubai,Iraq,Viet Nam,Ireland,Sinagpore,and so on .

Our goal is offer the best quality products with the lowest price and best service . We believe that our company will have a speed develop with the support from both at home and at abroad

We warmly welcome and looking forward to have a nice cooperation with company both at home and at abroad.

















FAQ

Q. How long can make delivery?

A:For stock products, will make shipments in 5- 7 days after receiving deposit or receiving L/C; for products need new production for common materials, usually make shipments in 15-20 days; for products need new production for special and rare materials, usually need 30-40 days to make shipment.



Q:Can you provide the samples?



A:Samples can be provided with samples charge and courier fee by the buyer's side.



Q:Are the products in stock?



A:Yes.Most of our products are in stock.So we can prompt delivery.



Q:Can you accept customize?



A:Yes.It can be customized as per the customers' request.



Q:What about the quality?



A:According to the standard for production.And we can also accept the third-party inspection



and quarantine.



About the After-Sale Service



a.We are glad that customers can give us some suggestions for price and products.



b.If you have any questions,pls feel free to contact us by email or phone.
