Hebei Hongcheng Pipe Fittings Co., Ltd.

P9 14" Hot Rolled Steel Pipe Sch40 Sch60 Sch80

Product Details:
Place of Origin: China
Brand Name: HongCheng
Certification: PED、ABS、BV、DNV、GL、LR、SGS、IEI
Model Number: 1/2" TO 24"
Payment & Shipping Terms:
Minimum Order Quantity: 0.5Ton
Price: Negotiable
Packaging Details: Standard export seaworthy package,or as required
Delivery Time: 7-15 work days
Payment Terms: L/C, D/P, T/T
Supply Ability: 2 Million Ton/Year
  • Detail Information
  • Product Description

Detail Information

Pressure: Sch30 Sch40 STD Sch60 Sch80 XS Sch100 Sch160 Standards: API, ASTM, Bs, DIN, GB, JIS, API 5CT, API 5L, ASTM A106-2006, ASTM A53-2007, ASTM A335-2006, ASTM A213M-2001, BS 1387, BS EN 39, DIN 2391, DIN 17175, GB/T 3091-2001, GB/T8162, Gb/t8163, JIS G3444-2006, JIS G3441
Material: P1, P2, P12, P11, P22, P5, P9, P91, P92,T1, T2, T11,T12, T5, T9, T22, ST52, X42, X46,X52,X60,X70,X80,X100,15CrMo,Cr5Mo,10CrMo910,12Cr2Mo,13CrMo44,12CrMo195,42CrMo,42CrMO4, X12CrMo91,12CrMo,etc Application: Alloy Steel Pipe Applies To Petroleum, Chemical Industry, Electric Power, Boiler, High Temperature Resistant, Low Temperature Resistant, Corrosion Resistant Part. The Size Of Alloy Steel Pipe Can Be Made According To The Customers Requirements.
Export Tosia,Spain,South Africa, Vier Nam,Peru,Dubai,etc.: Singapore,Indonesia,Ukraine,Brazil,Korea,Thailand,USA, UK,Canada,Saudi Arabia,Ireland,Oman,Rus Standard: Alloy Steel Seamless Pipe, Alloy Steel Pipe Gr P5, Alloy Steel Pipe Gr P11, Alloy Steel Pipe Gr P9, Alloy Steel Pipe Gr P22, Alloy Steel Pipe Gr P91, ASTM A335,
High Light:

p9 hot rolled steel pipe

,

14inch hot rolled steel pipe

,

sch40 alloy steel seamless pipe

Product Description

Astm A335 P9 14" Sch40 Sch60 Sch80 Xxs Alloy Steel Seamless Pipe Hot Rolled Steel Pipe



Alloy seamless steel pipe is a kind of seamless steel pipe, its performance is much higher than that of general seamless steel pipe, because this kind of steel pipe contains more Cr, its high temperature, low temperature and corrosion resistance performance is not compared with other seamless steel pipe, so alloy pipe is widely used in petroleum, chemical industry, electric power, boiler and other industries.
Alloy seamless steel pipe contains elements such as silicon, manganese, chromium, nickel, molybdenum, tungsten, vanadium, titanium, niobium, zirconium, cobalt, aluminum, copper, boron, rare earth, etc.
Alloy seamless steel pipe (Seamless Steel Tube) with hollow section, no joints around the strip steel. The steel pipe has a hollow section and is widely used as a pipeline for conveying fluid, such as oil, natural gas, gas, water and some solid materials. Compared with solid steel such as round steel, alloy seamless steel pipe is light weight when bending and torsion strength is the same. It is an economic section steel, which is widely used in the manufacture of structural parts and mechanical parts, such as oil conveying, stair handrails, bicycle frames and steel scaffolding used in construction. Making ring parts with alloy seamless steel pipe can improve material utilization, simplify manufacturing process, and save material and processing time, such as rolling bearing ring, Jack sleeve and so on. Steel pipe has been widely used to manufacture. Alloy seamless steel pipe or all kinds of conventional weapons indispensable materials, gun barrel, barrel and so on must be made of steel pipe. In addition, when the ring section is subjected to internal or external radial pressure, the force is more uniform, so most alloy seamless steel tubes are circular tubes
Production process
Hot rolling (extruded seamless steel pipe): pipe billet → heating → perforation → three-roll oblique rolling, continuous rolling or extrusion → pipe → diameter (or diameter reduction) cooling pipe straightening → hydraulic test (or flaw detection) marking → storage.
Cold drawn seamless steel pipe: round tube billet → heating → perforation → head → annealing → pickling → oiling (copper plating), multi-pass cold drawing (cold rolling)→ billet tube → heat treatment, straightening → water pressure test (flaw detection), marking → storage
Classification
Seamless steel pipe for structure: mainly used in general structure and mechanical structure. Its representative material (brand): carbon steel 20,45 steel; alloy steel Q345,20Cr,40Cr,20CrMo,30-35CrMo,42CrMo.
Seamless steel pipe for conveying fluid: mainly used for conveying fluid pipes on engineering and large equipment. representative material (brand number) is 20, Q345, etc.
Seamless steel pipe for low medium pressure boiler: mainly used in industrial boiler and domestic boiler to transport low medium pressure fluid pipeline. Representative material is 10,20 steel.
Seamless steel pipe for high pressure boiler: It is mainly used for high temperature and high pressure conveying fluid header and pipeline on power station and nuclear power plant boiler. Representative material is 20 G,12Cr1MoVG,15CrMoG, etc.
Carbon steel and carbon manganese steel seamless steel pipe for ship: mainly used for ship boiler and superheater I,II grade pressure resistant pipe. Representative material is 360,410,460 steel grade etc.
Seamless steel pipe for high pressure chemical fertilizer equipment: mainly used for conveying high temperature and high pressure fluid pipeline on chemical fertilizer equipment. representative material is 20,16 Mn,12CrMo,12Cr2Mo etc.
Seamless steel pipe for petroleum cracking: boiler, heat exchanger and its conveying fluid pipeline mainly used in petroleum smelter. and its representative material is 20,12 CrMo,1Cr5Mo,1Cr19Ni11Nb, etc.



ASTM A335

Low-Alloy

Steel

(Grades)

UNS

equivalent

C≤

Mn

P≤

S≤

Si≤

Cr

Mo

P1

K11522

0.10~0.20

0.30~0.80

0.025

0.025

0.10~0.50

0.44~0.65

P2

K11547

0.10~0.20

0.30~0.61

0.025

0.025

0.10~0.30

0.50~0.81

0.44~0.65

P5

K41545

0.15

0.30~0.60

0.025

0.025

0.5

4.00~6.00

0.44~0.65

P5b

K51545

0.15

0.30~0.60

0.025

0.025

1.00~2.00

4.00~6.00

0.44~0.65

P5c

K41245

0.12

0.30~0.60

0.025

0.025

0.5

4.00~6.00

0.44~0.65

P9

S50400

0.15

0.30~0.60

0.025

0.025

0.50~1.00

8.00~10.00

0.44~0.65

P11

K11597

0.05~0.15

0.30~0.61

0.025

0.025

0.50~1.00

1.00~1.50

0.44~0.65

P12

K11562

0.05~0.15

0.30~0.60

0.025

0.025

0.5

0.80~1.25

0.44~0.65

P15

K11578

0.05~0.15

0.30~0.60

0.025

0.025

1.15~1.65

0.44~0.65

P21

K31545

0.05~0.15

0.30~0.60

0.025

0.025

0.5

2.65~3.35

0.80~1.60

P22

K21590

0.05~0.15

0.30~0.60

0.025

0.025

0.5

1.90~2.60

0.87~1.13

P91

K91560

0.08~0.12

















Standards

Grades

Production Standards

GB 5310

15MoG,15CrMoG,15CrMo,12Cr2MoG,12Cr1MoV,12Cr2MoWVTiB,10Cr9Mo1VNb



ASTM A179

A179



ASTM A192

A192



ASTM A210

Gr.A-1 , Gr.C



ASTM A213

T2, T5, T5b, T5c, T9, T11, T12, T17, T21, T22, T91, T92



ASTM A333

Gr.4, Gr.9, Gr.10, Gr.11



ASTM A334

Gr.9, Gr.11



ASTM A335

P1, P2, P5, P5b, P5c, P9, P11, P12, P15, P21, P22, P91,P92



ASTM A519

1330, 1335, 3140, 4140, 4130, 4337,....etc.



DIN 17175

15Mo3, 10CrMo9 10, 13CrMo44, 14Mov63



EN 10216-2

P195GH, P235GH, P265GH, 16Mo3, 10CrMo9-10



JIS-G3341

SCr 420TK, SCM 415TK, SCM 418TK, SCM 420TK, SCM 430TK, SCM 435TK, SCM 440TK

Size

1/2 inch to 28 inch & Wall thickness (1.5 ~30) mm

Packing

Bundles with PE wrapping, Wooden case or customized



about us:

Hebei Hongcheng Pipe Industry Co., Ltd. was established in 1992 and is located in the Development Zone of Yanshan County, Hebei Province. We are one of the largest steel product manufacturers on the coast of the Bohai Sea. A three-dimensional comprehensive transportation network has been formed. Our geographical position is superior and the transportation is very convenient.

We are one of the biggest manufacturer for steel products with a 80, 000-square-meter workshop,covers an area more than 120,000 square meters in size ,and well over 50 million USD in assets.our main products including stainless steel pipe ,stainless steel plate,stainless steel bar,seamless steel pipe ,low temperature steel pipe ,alloy steel pipe ,boiler pipe ,carbon steel plate ,alloy steel plate ,pipe fitting,copper products,titanium products and nickel products.our company has the most advanced production equipment which guarantee the most advantageous product quality.Based on highly quality products and best service,we have develop clients all round the world ,our products are widely used in industry in USA ,Germany ,India ,Dubai,Iraq,Viet Nam,Ireland,Sinagpore,and so on .

Our goal is offer the best quality products with the lowest price and best service . We believe that our company will have a speed develop with the support from both at home and at abroad

We warmly welcome and looking forward to have a nice cooperation with company both at home and at abroad.



P9 14" Hot Rolled Steel Pipe Sch40 Sch60 Sch80 0



P9 14" Hot Rolled Steel Pipe Sch40 Sch60 Sch80 1

P9 14" Hot Rolled Steel Pipe Sch40 Sch60 Sch80 2

P9 14" Hot Rolled Steel Pipe Sch40 Sch60 Sch80 3



FAQ

Q. How long can make delivery?

A:For stock products, will make shipments in 5- 7 days after receiving deposit or receiving L/C; for products need new production for common materials, usually make shipments in 15-20 days; for products need new production for special and rare materials, usually need 30-40 days to make shipment.



Q:Can you provide the samples?



A:Samples can be provided with samples charge and courier fee by the buyer's side.



Q:Are the products in stock?



A:Yes.Most of our products are in stock.So we can prompt delivery.



Q:Can you accept customize?



A:Yes.It can be customized as per the customers' request.



Q:What about the quality?



A:According to the standard for production.And we can also accept the third-party inspection



and quarantine.



About the After-Sale Service



a.We are glad that customers can give us some suggestions for price and products.



b.If you have any questions,pls feel free to contact us by email or phone.
