Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | Hong Cheng |
| Certification: | PED、ABS、BV、DNV、GL、LR、SGS、IEI |
| Model Number: | 1/2" TO 72" |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1PCS |
| Price: | 10-100 pieces US $216/ Piece;>100 pieces US $189/ Piece |
| Packaging Details: | Plywood cases or pallets |
| Delivery Time: | 7-15 work days |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 2 Million Ton/Year |
|
Detail Information |
|||
| Certification:: | API CE ISO | Payment Terms:: | L/C, T/T |
|---|---|---|---|
| Size：: | Seamless From DN15-DN700; Welding:DN200-DN2000 | Standard: | ANSI B 16.9/ANSI B16.28/MSS SP43/MSS P75/JIS2311/JIS 2312/JIS2313/DIN2605 /GB-12459/GB-T13401 Etc… |
| Product Class: | 2D 3D 4D 5D 6D, 45°, 90° 180° | Material: | Stainless Steel，Alloy Steel |
| Packaging Details:: | Standard Package | Thickness：: | SCH10,SCH20,SCH30,STD,SCH40,SCH60,SCH80,SCH100,SCH120,SCH160,XS,XXS HIGH THICKNESS TO 80MM |
| High Light: | Stainless Steel 45 Degree Bend,Seamless 45 Degree Bend,API Stainless Steel Bend |
||
Product Description
China Hebei Hongcheng Pipe Industry Co., Ltd. |
|
PRODUCT TYPE |
90DEG ELBOW LR BW ASTM A 234 Gr WPB AS PER ASME B 16.9 Sch40,CS BW SML STPG370 ELBOW 90-LR SCH80,ANSI ASTM A53 GR A SCH STD 90D SRElbow,CS ASTM A105 WPB SCH80 90 Degree LR Elbow,Seamless Elbow 90 Degree LR, steel seamless elbows, pipe fitting elbow, 90 degreeelbow, pipe elbow, elbow fitting, seamless elbow, butt welding elbow, steel elbow, carbon steel elbow(CS elbow), mild steelelbow(MS elbow), alloy steel elbow(AS elbow),stainless steel elbow(SS elbow) |
SIZE |
NPS1/2”-120”(DN15-3000) |
WALL THICKNESS |
SCH5S/10S, SCH20/40/80/160, STD/XS/XXS, SGP……. |
MATERIAL |
carbon steel: ASTM A234 GR WPB , ST37.2 , ST35.8…… |
alloy steel: A234 WP5/WP9/WP11/WP22/WP91, A420 WPL6, A860 WHPY 42/52/60/65/70/80…… |
|
stainless steel: A403 WP304/TP304 , WP304L/TP304L , WP316/TP316 , WP316L/TP316L, WP321/TP321 , WP310/TP310….. |
|
STANDARD |
ANSI B 16.9/ANSI B16.28/MSS SP43/MSS P75/JIS2311/JIS 2312/JIS2313/DIN2605 /GB-12459/GB-T13401 etc… |
we can also produce according to drawing by customers. |
|
Product Name |
pipe Bend |
Material |
A234WPB, A420WPL6 St37,St45, E24, A42CP, 16Mn, Q345, P245GH, P235GH, P265GH, P280GH,P295GH,P355GHWPHY42, WPHY52, WPHY60, WPHY65,WPHY70, WPHY80P11,P22,P5, P9,P91, 10CrMo9-10, 16Mo3 |
Wall thickness |
sch20,sch30,sch40,STD,sch60,XS,sch80,sch120,XXS,etc |
Standard |
ANSI B16.9, EN10253-2, DIN2605, GOST17375-2001, JIS B2313, MSS SP 75 |
Types |
30D, 45D, 60D, 90D, 180D, R=1D/1.5D |
Surface treatment |
black painting, anti-rust oil |
Package |
pallets, wooden cases, containers |
Used |
Petrochemical industy;avation and aerospace industry;pharmaceutical industry;gas exhaust;power plart;ship buliding;water treament,etc. |
