Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | Hong Cheng |
| Certification: | PED、ABS、BV、DNV、GL、LR、SGS、IEI |
| Model Number: | 1/2" TO 72" |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1PCS |
| Price: | 10-100 pieces US $216/ Piece;>100 pieces US $189/ Piece |
| Packaging Details: | Plywood cases or pallets |
| Delivery Time: | 7-15 work days |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 2 Million Ton/Year |
|
Detail Information |
|||
| Certification:: | API CE ISO | Payment Terms:: | L/C, T/T |
|---|---|---|---|
| Thickness：: | SCH10,SCH20,SCH30,STD,SCH40,SCH60,SCH80,SCH100,SCH120,SCH160,XS,XXS HIGH THICKNESS TO 80MM | Size：: | Seamless From DN15-DN700; Welding:DN200-DN2000 |
| Product Class: | 2D 3D 4D 5D 6D, 45°, 90° 180° | Face:: | Special Coating I.e. Cement Mortar Lining, FBE Coating, Galvanized (Hot Dipped Electro-Plating) Etc. Can Be Provided |
| High Light: | Wp5 Steel Pipe Bend,Sch40 Steel Pipe Bend,180 Return Bend 10Inch |
||
Product Description
Products |
Seamless Butt-Welded Alloy Steel Pipe Fittings |
|
Brand: |
Hongcheng |
|
Item |
Elbow L/R S/R,Equal Tee,Reducing Tee,Concentric Reducer,Eccentric Reducer,Cap, Bend |
|
Standard |
ASME |
ANSI B16.9,ANSI B16.28,MSS-SP-75 |
DIN |
DIN2605,DIN2615, DIN2616, DIN2617, DIN28011 |
|
SGP |
JISB2313 |
|
EN |
EN10253-1 EN10253-2 |
|
Material |
ASME |
A234 WPB,A234 WP1,A234 WP5,A234,WP9, |
A234 WPB11,A234 WPB12,A234 WPB22,WP91, |
||
A420,WPHY42,WPHY52,WPHY60,WPHY65, |
||
WPHY70,WP304,WP304L,WP304H,WP316, |
||
WP316L,WP321,WP347,WP347H |
||
DIN |
ST37.0,ST35.8,ST45.8,S235JR,P235GH,P265GH, |
|
10CrMo910,15CrMo,12Cr1MoV |
||
JIS |
JIS G3454,STPG370,TPG410 |
|
Surface |
Black paint/bright paint/Galvanized |
|
Marking |
As customer’s requirements |
|
Package |
By strong plywood cases |
|
Delivery |
Within 30 days |
|
Certificate |
PED, ISO9001:2008 |
|
Description |
Stainless Steel,Alloy Steel pipe bend fittings |
Standard |
ASTM B16.9,ASME B16.49, Customized |
Material |
A234 WP5/P9/P11/P12/P22/P91A860 WPHY 52/60/65A403 WP304/304L/316/316L/32113CrMo44 10CrMo910 12CrMo195 Cr5Mo 15CrMo 12Cr2Mo |
Size |
Outside Diameter: 6-2400mm Wall Thickness:1.0-200mm Length: 1-12m |
Surface |
Mill,Painted,Anti-rust Coated,etc |
Application |
Boiler Pipe,Chemical Fertilize Pipe,Oil/Gas Pipe,Fluid Pipe,Drill Pipe,Hydraulic Pipe,Structure Pipe,etc |
