Hebei Hongcheng Pipe Fittings Co., Ltd.

A234GR. WP5-S Alloy Steel Seamless Eccentric Reducer 6"X3"XS40

Product Details:
Place of Origin: China
Brand Name: hongcheng
Certification: PED、ABS、BV、DNV、GL、LR、SGS、IEI
Model Number: 2" TO 32 "
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Packaging Details: Plywood Cases or Pallets
Delivery Time: 7-15 work days
Payment Terms: L/C, D/P, T/T
Supply Ability: 200,000 tons/year
  • Detail Information
  • Product Description

Detail Information

Size: 1/2"-24" Seamless, 26"-80" Welded Material: Stainless Steel,Alloy
Type: Reducer Standard: ASME
Type: Seamless And Welded End: Bevel End/BE/buttweld
High Light:

Alloy Steel Seamless Eccentric Reducer

,

ASME Seamless Eccentric Reducer

,

Concentric Alloy Steel Reducer

Product Description



A234GR. WP5-S alloy steel seamless concentric size head 6"*3"*S40 quality assurance

about us:

Hebei Hongcheng Pipe Industry Co., Ltd. was established in 1992 and is located in the Development Zone of Yanshan County, Hebei Province. We are one of the largest steel product manufacturers on the coast of the Bohai Sea. A three-dimensional comprehensive transportation network has been formed. Our geographical position is superior and the transportation is very convenient.

We are one of the biggest manufacturer for steel products with a 80, 000-square-meter workshop,covers an area more than 120,000 square meters in size ,and well over 50 million USD in assets.our main products including stainless steel pipe ,stainless steel plate,stainless steel bar,seamless steel pipe ,low temperature steel pipe ,alloy steel pipe ,boiler pipe ,carbon steel plate ,alloy steel plate ,pipe fitting,copper products,titanium products and nickel products.our company has the most advanced production equipment which guarantee the most advantageous product quality.Based on highly quality products and best service,we have develop clients all round the world ,our products are widely used in industry in USA ,Germany ,India ,Dubai,Iraq,Viet Nam,Ireland,Sinagpore,and so on .

Our goal is offer the best quality products with the lowest price and best service . We believe that our company will have a speed develop with the support from both at home and at abroad

We warmly welcome and looking forward to have a nice cooperation with company both at home and at abroad.



A234GR. WP5-S Alloy Steel Seamless Eccentric Reducer 6"X3"XS40 0



Specification List

Porduct Name Carbon Steel /Stainless Steel Concentric/Eccentric Reducer
Size 1/2"-24" seamless, 26"-80" welded
Standard ANSI B16.9, EN10253-2, DIN2616, JIS B2311,
Wall thickness STD, SCH20,SCH30,SCH40, SCH60, SCH80, SCH160, DIN,JIS and etc.
Type Seamless and Welded
End Bevel end/BE/buttweld
Surface nature color, varnished, black painting, anti-rust oil etc.
Material

Carbon steel: A234WPB, A420WPL6 St37,St45, E24, A42CP, 16Mn, Q345, P245GH,

P235GH, P265GH, P280GH,P295GH,P355GH etc.

Pipeline steel: WPHY42, WPHY52, WPHY60, WPHY65,WPHY70, WPHY80 and etc.
Cr-Mo alloy steel: P11,P22,P5, P9,P91, 10CrMo9-10, 16Mo3 etc.
Application

Petrochemical industy;avation and aerospace industry;pharmaceutical industry;

gas exhaust;power plant;ship buliding;water treament,etc.

Advantages ready stock,faster delivery time;available in all sizes,austomized;high quality








Chemical Composition (%) of ASTM A234:

Grade C Mn P S Si Cr Mo Ni Cu V Nb
WPB 0.3 0.29-1.06 0.05 0.058 0.1min 0.4 0.15 0.4 0.4 0.08 0.02
WPC 0.35 0.29-1.06 0.05 0.058 0.1min 0.4 0.15 0.4 0.4 0.08 0.02
WP11 CL1 0.05-0.15 0.30-0.60 0.03 0.03 0.50-1.00 1.00-1.50 0.44-0.65 - - - -
WP11 CL2/3 0.05-0.20 0.30-0.80 0.04 0.04 0.50-1.00 1.00-1.50 0.44-0.65 - - - -

A234GR. WP5-S Alloy Steel Seamless Eccentric Reducer 6"X3"XS40 1

A steel pipe reducer is a component used in the pipelines to reduce its size from large to small bore in accordance to the inner diameter. The length of the reduction here is equal to an average of the smaller and larger pipe diameters. Here, the reducer can be used as a diffuser or a nozzle. The reducer helps in meeting the existing piping of varied sizes or hydraulic flow of the piping systems.

The usage of a steel reducer is carried out in the chemical factories and power plants. It makes the piping system reliable and compact. It safeguards the piping system from any kind of adverse impact or thermal deformation. When it is on the pressure circle, it prevents from any type of leakage and is easy to install. The nickel or chrome coated reducers extends the product life, useful for high vapor lines, and prevents corrosion.

Reducer Types

There are two types of reducer, concentric reducer and eccentric reducer.

Concentric Reducer




Code RCD REISO Ø BIG Ø SMALL HEIGHT H mm THEORETICAL WEIGHT KG
  DN D mm Thickness S mm DN d mm Thickness s mm
27 21 3/4 26.9 2.3 1/2 21.3 2.0 38 0.08
33 21 1 33.7 2.6 1/2 21.3 2.0 50 0.09
33 27       3/4 26.9 2.3   0.09
42 21 1″1/4 42.4 2.6 1/2 21.3 2.0 50 0.12
42 27       3/4 26.9 2.3   0.13
42 33       1 33.7 2.6   0.14
*48 21 1″1/2 48.3 2.6 1/2 21.3 2.0 64 0.18
48 27       3/4 26.9 2.3   0.19
48 33       1 33.7 2.6   0.20
48 42       1″1/4 42.4 2.6   0.20
60 27 2 60.3 2.9 3/4 26.9 2.3 76 0.30
60 33       1 33.7 2.6   0.31
60 42       1″1/4 42.4 2.6   0.32
60 48       1″1/2 48.3 2.6   0.33
76 33 2″1/2 76.1 2.9 1 33.7 2.6 90 0.40
76 42       1″1/4 42.4 2.6   0.47
76 48       1″1/2 48.3 2.6   0.48
76 60       2 60.3 2.6   0.49
89 42 3 88.9 3.2 1″1/4 42.4 2.6 90 0.55
89 48       1″1/2 48.3 2.6   0.61
89 60       2 60.3 2.9   0.62
89 76       2″1/2 76.1 2.9   0.63
114 48 4 114.3 3.6 1″1/2 48.3 2.6 100 0.85
114 60       2 60.3 2.9   0.98
114 76       2″1/2 76.1 2.9   1.00
114 89       3 88.9 3.2   1.02
139 60 5 139.7 4.0 2 60.3 2.9 127 1.60
139 76       2″1/2 76.1 2.9   1.70
139 89       3 88.9 3.2   1.74
139 114       4 114.3 3.6   1.76
*168 76 6 168.3 4.5 2″1/2 76.1 2.9 140 2.60
168 89       3 88.9 3.2   2.70
168 114       4 114.3 3.6   2.82
168 139       5 139.7 4.0   2.94
219 114 8 219.1 6.3 4 114.3 3.6 152 5.03
219 139       5 139.7 4.0   5.12
219 168       6 168.3 4.5   5.18
*273 114 10 273.0 6.3 4 114.3 3.6 178 7.00
*273 139       5 139.7 4.0   7.20
273 168       6 168.3 4.5   7.40
273 219       8 219.1 6.3   7.55
323 168 12 323.9 7.1 6 168.3 4.5 203 11.00
323 219       8 219.1 6.3   11.10
323 273       10 273 6.3   11.20


A234GR. WP5-S Alloy Steel Seamless Eccentric Reducer 6"X3"XS40 2

A234GR. WP5-S Alloy Steel Seamless Eccentric Reducer 6"X3"XS40 3
A234GR. WP5-S Alloy Steel Seamless Eccentric Reducer 6"X3"XS40 4

FAQ
Q. How long can make delivery?
A:For stock products, will make shipments in 5- 7 days after receiving deposit or receiving L/C; for products need new production for common materials, usually make shipments in 15-20 days; for products need new production for special and rare materials, usually need 30-40 days to make shipment.

Q:Can you provide the samples?

A:Samples can be provided with samples charge and courier fee by the buyer's side.

Q:Are the products in stock?

A:Yes.Most of our products are in stock.So we can prompt delivery.

Q:Can you accept customize?

A:Yes.It can be customized as per the customers' request.

Q:What about the quality?

A:According to the standard for production.And we can also accept the third-party
