Alloy Material 6 Inch Steel Pipe Flange , F22 Astm A182 Flanges Class 900
Alloy Material 6 Inch Steel Pipe Flange , F22 Astm A182 Flanges Class 900
Alloy Material 6 Inch Steel Pipe Flange , F22 Astm A182 Flanges Class 900 Alloy Material 6 Inch Steel Pipe Flange , F22 Astm A182 Flanges Class 900 Alloy Material 6 Inch Steel Pipe Flange , F22 Astm A182 Flanges Class 900

Alloy Material 6 Inch Steel Pipe Flange , F22 Astm A182 Flanges Class 900

Product Details:
Place of Origin: Yanshan, Hebei, China
Brand Name: HongCheng
Certification: PED、ABS、BV、DNV、GL、LR、SGS、IEI
Model Number: 1/2" TO 120 "
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: 10-100 pieces US $4.48/ Piece;>100 pieces US $3.62/ Piece
Packaging Details: Plywood Cases or Pallets
Delivery Time: 7-15 work days
Payment Terms: L/C, D/P, T/T
Supply Ability: 2 Million Ton/Year
Contact Now
  • Detail Information
  • Product Description

Detail Information
Size :: 1/2" - 120" Pressure :: Class150/300/600/9001500/2500,Class150,150#-2500#,5K-30K
Material :: Stainless Steel,alloy Steel Standard :: ANSI B16.5,EN1092-1, SABA1123, JIS B2220, DIN, GOST,UNI,AS2129, API 6A, Etc.
Type :: Blind,weld Neck Flange,threaded,Pipe Flange,socket Welding Packaging Details :: Wooden Box, Pallet Or According To Customer Requirements
High Light:

Alloy 6 Inch Steel Pipe Flange

,

F22 6 Inch Steel Pipe Flange

,

Class 900 Astm A182 Flanges

Product Description

High Pressure Pipe Flanges Astm A182 F22 6" 900# Alloy Steel Flanges Asme B16.5 Standard ​

Process flow

Company Introduce

We have five branch factories which can supply the best quality pipes, tubes, fittings flanges and related accessories. Now, it owns a number of advanced pipe production equipments, metal, forging, machining, cold forming, hot extrusion, such as heat treatment process, producing 60, 000 tons of pipe fittings. Company with a variety of detection devices, such as nondestructive testing, chemical analysis, metallographic examination, physical experiments. The technical is very strength, our main products contain fittingsforged socket welding fittings and threaded fittings, pipe weld and the materials of the products contain stainless steel ,duplex-stainless steel alloy steel.

Alloy Material 6 Inch Steel Pipe Flange , F22 Astm A182 Flanges Class 900 0

Alloy Material 6 Inch Steel Pipe Flange , F22 Astm A182 Flanges Class 900 1

Flange Type

Slip-on Flange / Blind Flange/ Reducing Flange / Welding Neck Flange / Orifice Flange / Lap Joint Flange /

Threaded Flange / Socket Flange

Grade

Cr

Ni

Cu

W

Si

Mn

Mo

N

P Max

S Max

C Max

Fe

S32760

25.5

6.4

3.5

0.75

1.00

1.00

3.5

0.25

0.030

0.010

0.030

Bal



FlangeType

Steel Flange, Alloy Steel Flange, Alloy 625, Alloy 690, Alloy 718

Standard

ASME/ANSI B16.5

Size

1/2’’~60’’

Pressure Rate

150lb to 2500lb

Manufacturing process

Push, Press, Forge, Cast, etc.

Material

Inconel Alloy Steel Flange

Carbon steel

ASTM A 105

Allloy steel flange

ASTM A182 F5; F11;F22;F91;F51

ASTM A350 LF1; LF2; A350 LF3 ;LF4;LF6;LF8

Stainless Steel flange

ASTM A182 F304/304H/304L

ASTM A182 F316/316H/316L

ASTM A182 F321/321H

ASTM A182 F347/347H

Manufacture Standard

ANSI : ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48
DIN :DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673
B.S : BS4504 , BS4504, BS1560, BS10

Package

Wooden cases, pallets, nylon bags or according to the customers' requirements

MOQ

1pcs

Delivery time

10-100 days depending on quantity

Payment terms

T/T or Western Union or LC

Shipment

FCA Tianjin/Shanghai, CFR, CIF, etc

Application

Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc

Remarks

Other materials and drawings are available.

Mechanical Properties

Grade

UTS N/mm2(min)

0.20% Proolf(min)

Elong%(min)

Hardness HB (max)

PREN

S32760

750

550

25

270

40

Related Material

Material

Carbon steel(ASTM A105,A350LF2,A350LF3,)

Stainless steel(ASTM A182 F304, F304L,F316,F316L,F321,

F347,F310F44F51,A276 S31803, A182,

F43, A276 S32750,A705 631,632,A961, A484,

Alloy steel(ASTM A694 F42,F46,F52,F56,F60,F65,F70, A182

T91 (P91)

F12,F11,F22,F5,F9,F91,F1ECT)

Standard

DIN,EN,ASTM,BS,JIS,GB,ASME(ASME16.9/16.20)

Application

Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc

Nickel Alloy
Standard

· ASTM / ASME SB 336

· UNS 10276 (HASTELLOY C 276 )

· UNS 2200 (NICKEL 200 )

· UNS 2201 (NICKEL 201 )

· UNS 4400 (MONEL 400 )

· UNS 8020 (ALLOY 20 / 20) CB 3

· UNS 8825 INCONEL (825 )

· UNS 6600 (INCONEL 600 )

· UNS 6601 (INCONEL 601 )

· UNS 6625 (INCONEL 625 )

· UNS 5500(MONEL K500)

· UNS 8800(INCONEL 800)

· UNS 8810(INCONEL 800H)

FAQ

1. Are you trading company or manufacturer ?

We are manufacturer .

2. How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

3. Do you provide samples ? is it free or extra ?

Yes, we could offer the sample for free charge but need pay the cost of freight.

4. What is your terms of payment ?

Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shipment.

Alloy Material 6 Inch Steel Pipe Flange , F22 Astm A182 Flanges Class 900 2

Alloy Material 6 Inch Steel Pipe Flange , F22 Astm A182 Flanges Class 900 3

Alloy Material 6 Inch Steel Pipe Flange , F22 Astm A182 Flanges Class 900 4



Alloy Material 6 Inch Steel Pipe Flange , F22 Astm A182 Flanges Class 900 5
