Hebei Hongcheng Pipe Fittings Co., Ltd.

Gas Carbon Steel Pipe Tee Asme A234 B16.9 1/2''- 44" Sch-Xxs Butt Welded Seamless

Product Details:
Place of Origin: China
Brand Name: hongcheng
Certification: PED、ABS、BV、DNV、GL、LR、SGS、IEI
Model Number: 6" TO 22 "
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: consult
Packaging Details: Plywood Cases or Pallets
Delivery Time: 7-15 work days
Payment Terms: L/C, D/P, T/T
Supply Ability: 100000Tons per year
  • Detail Information
  • Product Description

Detail Information

Manufacture Standard:: ASME B16.9,ASME B16.11,ASME B16.28 ,MSS SP-43,JISB2311,JIS B2312,JIS B2313,DIN 2605,DIN2606 ,DIN2615,DIN2616 ,BG12459-90, GB/T13401,HGJ514 ,SH3408 ,SH3409, HG/T21635, HG/T21631, Thickness: Sch5S~Sch160XXS
Size Range:: 1/2’~10’(Seamless);12’~72’(Welded) Certificate:: API, And ISO9001:2000 Certificates,CE,BV, Etc.
Surface Treatment:: Rolling Sand Blasting Pickling Payment Terms :: T/T Or Western Union Or LC
High Light:

44" carbon steel pipe tee

,

sch xxs carbon steel pipe tee

,

asme gas carbon steel tee

Product Description

Gas Asme A234 B16.9 Carbon Steel Pipe Tee1/2''- 44"Sch-Xxs Butt Welded Seamless

Product Description:

The alloy tee is a necessary product that we need to use when installing some pipes. The alloy tee is a connecting pipe fitting, which can realize the connection of two pipes with the same diameter, and can make the angle of the two pipes at 90 degrees. It can also be from other angles, so how much do you know about alloy tee? Do you know the production method of alloy tee? Let's take a look at some related introductions of alloy tee.
Alloy tee is composed of a variety of elbows, not only in rich styles, but also in various materials made of alloy tee. The alloy tee that we often see are carbon steel alloy tee, manganese steel alloy Tee and nickel steel alloy tee and so on.
Alloy tee has a very wide range of uses in our daily life. In general, alloy tee made of bronze is mainly used in the connection of some tap water pipes. This is the most common alloy tee pipe we see. Our living standards are improving day by day, and now we can also see stainless steel alloy tee fittings in tap water pipes.
The alloy tee made of manganese steel is a kind of alloy tee with strong bearing capacity. It can withstand strong impact and has anti-extrusion characteristics. It is widely used in pipes for conveying concrete, although it will be worn to a large extent. pipe fittings, but it will not affect its effect







Technical Drawing Size Specification

Gas Carbon Steel Pipe Tee Asme A234 B16.9 1/2''- 44" Sch-Xxs Butt Welded Seamless 0

Unit : inch

Nominal

Outside Dia.

(OD)

Wall Thickness (T)

Tees Center To

Ends C.M

Sch.5S

Sch.10S

Sch.40S

Sch.80S

1/2

0.840

0.065

0.083

0.109

0.147

1.00

3/4

1.050

0.065

0.083

0.113

0.154

1.13

1

1.315

0.065

0.109

0.133

0.179

1.50

1-1/4

1.660

0.065

0.109

0.140

0.191

1.88

1-1/2

1.900

0.065

0.109

0.145

0.200

2.25

2

2.375

0.065

0.109

0.154

0.218

2.50

2-1/2

2.875

0.083

0.120

0.203

0.276

3.00

3

3.500

0.083

0.120

0.216

0.300

3.38

4

4.500

0.083

0.120

0.237

0.337

4.13

5

5.563

0.109

0.134

0.258

0.375

4.88

6

6.625

0.109

0.134

0.280

0.432

5.63

8

8.625

0.109

0.148

0.322

0.500

7.00

10

10.750

0.134

0.165

0.375

0.500

8.50

12

12.750

0.156

0.180

0.375

0.500

10.00

14

14.000

0.156

0.250

0.375

0.500

11.00

16

16.000

0.165

0.250

0.375

0.500

12.00

18

18.000

0.165

0.250

0.375

0.500

13.50

20

20.000

0.188

0.250

0.375

0.500

15.00

24

24.000

0.218

0.250

0.375

0.500

17.00



Gas Carbon Steel Pipe Tee Asme A234 B16.9 1/2''- 44" Sch-Xxs Butt Welded Seamless 1

Duplex 2205 Mechanical Properties

Density

Melting Point

Yield Strength (0.2%Offset)

Tensile Strength

Elongation

7.8 g/cm3

1350 °C (2460 °F)

Psi – 80000 , MPa – 550

Psi – 116000 , MPa – 800

15%



Gas Carbon Steel Pipe Tee Asme A234 B16.9 1/2''- 44" Sch-Xxs Butt Welded Seamless 2

STANDARD

ASME/ANSI B16.9, B16.11, B16.28, JIS B2311, B2312, B2312, B2316
ASTM A403 MSS SP-43, SP-83, SP-97

MODEL

1.Tee (Straight and Reducing)

2.180 DEG Return

3.Elbow (45/90/180 DEG)

4.Cap

5. Reducer (Concentric and Eccentric)

TYPE

Seam Or Seamless

ELBOW DEGREE

45 degree, 90 degree, 180 degree

SURFACE

Black Paint, Anti Rust Oil, Hot-Dipped Galvanize

WALL THICKNESS

SCH5S, SCH10S, SCH10, SCH20, SCH30, SCH40, STD, XS, SCH60

SCH80, SCH100, SCH120, SCH140, SCH160, XXS, 2MM

SIZE

1/2"-48"(Dn15-Dn1200)

CONNECTION

Welding

SHAPE

Equal, Reducing

CERTIFICATE

ISO9001 API TUV

APPLICATION

Petrochemical & Gas industry, Power industry, Valve industry, Water works, Shipbuilding industry, Construction etc



Gas Carbon Steel Pipe Tee Asme A234 B16.9 1/2''- 44" Sch-Xxs Butt Welded Seamless 3



Q: Can you supply Forme, Cerficiate of origin?
A: Yes, we can supply.



Q: Can you supply invoice and CO with chamber of commerce?
A: Yes, we can supply.



Q: Can you accept L/C deferred 30, 60, 90days?
A: We can. Please negotiate with sales.



Q: Can you accept O/A payment?
A: We can. Please negotiate with sales.



Q: Can you supply samples?
A: Yes, some samples are free, please check with sales.



Q: Do you provide samples? Is it free or extra?
A: Yes, we can provide samples for free but you will afford the shipping cost.
