Gas Asme A234 B16.9 Carbon Steel Pipe Tee 18" Xs Butt Welded Seamless

Product Details:

Place of Origin:

China

Brand Name:

hongcheng

Certification:

PED、ABS、BV、DNV、GL、LR、SGS、IEI

Model Number:

6" TO 22 "

Payment & Shipping Terms:

Minimum Order Quantity:

1PC

Price:

consult

Packaging Details:

Plywood Cases or Pallets

Delivery Time:

7-15 work days

Payment Terms:

L/C, D/P, T/T

Supply Ability:

100000Tons per year

Detail Information

Manufacture Standard::

ASME B16.9,ASME B16.11,ASME B16.28 ,MSS SP-43,JISB2311,JIS B2312,JIS B2313,DIN 2605,DIN2606 ,DIN2615,DIN2616 ,BG12459-90, GB/T13401,HGJ514 ,SH3408 ,SH3409, HG/T21635, HG/T21631,

Application::

Petrochemical, Electric Power, Gas, Metallurgy, Shipbuilding, Construction, Etc.

Thickness:

Sch5S~Sch160XXS

Size Range::

1/2’~10’(Seamless);12’~72’(Welded)

Certificate::

API, And ISO9001:2000 Certificates,CE,BV, Etc.

Surface Treatment::

Rolling Sand Blasting Pickling

Payment Terms ::

T/T Or Western Union Or LC

High Light:

18 inch carbon steel pipe tee

butt welded carbon steel pipe tee

Asme A234 B16.9 Carbon Steel Pipe 18" Xs Butt Welded Seamless T-Pipe Tee Fitting

Product Description:

The alloy tee is a necessary product that we need to use when installing some pipes. The alloy tee is a connecting pipe fitting, which can realize the connection of two pipes with the same diameter, and can make the angle of the two pipes at 90 degrees. It can also be from other angles, so how much do you know about alloy tee? Do you know the production method of alloy tee? Let's take a look at some related introductions of alloy tee.
Alloy tee is composed of a variety of elbows, not only in rich styles, but also in various materials made of alloy tee. The alloy tee that we often see are carbon steel alloy tee, manganese steel alloy Tee and nickel steel alloy tee and so on.
Alloy tee has a very wide range of uses in our daily life. In general, alloy tee made of bronze is mainly used in the connection of some tap water pipes. This is the most common alloy tee pipe we see. Our living standards are improving day by day, and now we can also see stainless steel alloy tee fittings in tap water pipes.
The alloy tee made of manganese steel is a kind of alloy tee with strong bearing capacity. It can withstand strong impact and has anti-extrusion characteristics. It is widely used in pipes for conveying concrete, although it will be worn to a large extent. pipe fittings, but it will not affect its effect

Technical Drawing Size Specification

Unit : inch Nominal	Outside Dia. (OD)	Wall Thickness (T)				Tees Center To Ends C.M
Unit : inch Nominal	Outside Dia. (OD)	Sch.5S	Sch.10S	Sch.40S	Sch.80S	Tees Center To Ends C.M
1/2	0.840	0.065	0.083	0.109	0.147	1.00
3/4	1.050	0.065	0.083	0.113	0.154	1.13
1	1.315	0.065	0.109	0.133	0.179	1.50
1-1/4	1.660	0.065	0.109	0.140	0.191	1.88
1-1/2	1.900	0.065	0.109	0.145	0.200	2.25
2	2.375	0.065	0.109	0.154	0.218	2.50
2-1/2	2.875	0.083	0.120	0.203	0.276	3.00
3	3.500	0.083	0.120	0.216	0.300	3.38
4	4.500	0.083	0.120	0.237	0.337	4.13
5	5.563	0.109	0.134	0.258	0.375	4.88
6	6.625	0.109	0.134	0.280	0.432	5.63
8	8.625	0.109	0.148	0.322	0.500	7.00
10	10.750	0.134	0.165	0.375	0.500	8.50
12	12.750	0.156	0.180	0.375	0.500	10.00
14	14.000	0.156	0.250	0.375	0.500	11.00
16	16.000	0.165	0.250	0.375	0.500	12.00
18	18.000	0.165	0.250	0.375	0.500	13.50
20	20.000	0.188	0.250	0.375	0.500	15.00
24	24.000	0.218	0.250	0.375	0.500	17.00

STANDARD	ASME/ANSI B16.9, B16.11, B16.28, JIS B2311, B2312, B2312, B2316 ASTM A403 MSS SP-43, SP-83, SP-97
MODEL	1.Tee (Straight and Reducing)
	2.180 DEG Return
	3.Elbow (45/90/180 DEG)
	4.Cap
	5. Reducer (Concentric and Eccentric)
TYPE	Seam Or Seamless
ELBOW DEGREE	45 degree, 90 degree, 180 degree
SURFACE	Black Paint, Anti Rust Oil, Hot-Dipped Galvanize
WALL THICKNESS	SCH5S, SCH10S, SCH10, SCH20, SCH30, SCH40, STD, XS, SCH60
WALL THICKNESS	SCH80, SCH100, SCH120, SCH140, SCH160, XXS, 2MM
SIZE	1/2"-48"(Dn15-Dn1200)
CONNECTION	Welding
SHAPE	Equal, Reducing
CERTIFICATE	ISO9001 API TUV
APPLICATION	Petrochemical & Gas industry, Power industry, Valve industry, Water works, Shipbuilding industry, Construction etc

Q: Can you supply Forme, Cerficiate of origin?
A: Yes, we can supply.

Q: Can you supply invoice and CO with chamber of commerce?
A: Yes, we can supply.

Q: Can you accept L/C deferred 30, 60, 90days?
A: We can. Please negotiate with sales.

Q: Can you accept O/A payment?
A: We can. Please negotiate with sales.

Q: Can you supply samples?
A: Yes, some samples are free, please check with sales.

Q: Do you provide samples? Is it free or extra?
A: Yes, we can provide samples for free but you will afford the shipping cost.
