Product Description
ASME SB366 WPNCMC REDUCER ASTM B366 WPNCMC SEAMLESS BUTT WELD FITTINGS 90 DEGREE SCH40 STEEL PIPE REDUCER
WHAT IS ASTM B366 GRADE WPNCMC FITTINGS?
ASTM B366 GRADE WPNCMC FITTINGS are a kind of a weldable pipe fitting which permits a change in the direction of flow, to branch off or to reduce the size of the pipe.
SPECIFICATION OF ASTM B366 GRADE WPNCMC FITTINGS~
SIZE |
ASTM B366 WPNCMC Seamless Butt Weld Fittings: 1/2" - 10" ASTM B366 GRADE WPNCMC Welded Butt Weld Fittings: 1/2" - 48" |
DIMENSIONS | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
THICKNESS | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
TYPES |
ASTM B366 GRADE WPNCMC Buttweld Fitting ASME SB366-WPNCMC Seamless Fittings B366 gr WPNCMC ERW Fittings ASME SB366-WPNCMC Welded Fittings B366 WPNCMC Fabricated Pipe Fittings ASTM B366 GRADE WPNCMC Bevel Ends Pipe Fittings |
OD | DN15-DN1200 |
CONNECTION | Welding |
BEDING RADIUS | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASME SB366 WPNCMC Pipe Fitting |
RANGE | ½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM B366-WPNCMC Buttweld Fitting |
DEGREE OF ELBOW |
Angle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D, 4D, 5D, 6D, 7D-40D . Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO |
PROCESS | Push, Press, Forge, Cast, etc. |
TEST |
EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report(charged) |
3.1 MTC IS OFFERED AFTER THE ORDER PLACED AND SHIPPED TOGETHER WITH THE CARGO.
DIAMENSION OF ASTM B366 GRADE WPNCMC FITTINGS~
Nominal Pipe Size | All Fittings | All Fittings | All Fittings | Elbows/ Tees | 180° Return Bends | 180° Return Bends | 180 Deg Return Bends | Reducers | Caps |
NPS | O.D. at Bevel (1), (2) |
I.D. at End (1), (3), (4) |
Wall Thickness (3) | Centre-to-End Dimension A,B,C,M | Centre-to-Centre O | Back-to-Face K | Alignment of Ends U | Overall Length H | Overall Length E |
½ to 2½ |
0.06 -0.03 |
0.03 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
3 to 3 ½ | 0.06 | 0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
4 | 0.06 | 0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
5 to 8 |
0.09 -0.06 |
0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.25 |
10 to 18 |
0.16 -0.12 |
0.12 | Not less than 87.5% of nominal thickness | 0.09 | 0.38 | 0.25 | 0.06 | 0.09 | 0.25 |
20 to 24 |
0.25 -0.19 |
0.19 | Not less than 87.5% of nominal thickness | 0.09 | 0.38 | 0.25 | 0.06 | 0.09 | 0.25 |
26 to 30 |
0.25 -0.19 |
0.19 | Not less than 87.5% of nominal thickness | 0.12 | … | … | … | 0.19 | 0.38 |
32 to 48 |
0.25 -0.19 |
0.19 | Not less than 87.5% of nominal thickness | 0.19 | … | … | … | 0.19 | 0.38 |
1 | Material: |
carbon steel (ASTM A234WPS, A234WPC, A420 WPL6), (ST45.8 A105 A106 STG42) Alloy steel(ASTM A234 WP12/WP11/WP22/WP5/WP9/WP91) Stainless steel(ASTM A403 WP304/WP304L/WP316/WP316L) |
2 | Standard: | ASME/ANSI B16.9, DIN2650,2615,2616,2617,JIS B2311, 2312,2313, EN 10253-11, EN10253-2, GB |
3 | Size: | 1/2inch~48inch |
4 | Thickness: | SCH10,SCH20,SCH30,SCH STD, SCH40, SCH60,SCH XS, SCH80, SCH100, SCH120,SCH140,SCH160,SCH XXS |
5 | Type: | Elbow, tee, reducer, nipple, plug, union, bushing, cap, etc |
6 | Surface: | Transparent oil, rust-proof black oil, hot galvanized |
7 | Weight: | Heavy light, light weight |
8 | MOQ: | 1 piece |
9 | Packaging: |
1)Wooden case 2)Pallet 3)As per customer’s requirements |
10 | Application: | Oil, chemical industrial, water conservancy, electric power, boiler, machinery, metallurgy, etc |
