Astm A234 Pipe Connector T P91 P22 A213 12cr1movg Alloy Seamless

Product Details:
Place of Origin: China
Brand Name: hongcheng
Certification: PED、ABS、BV、DNV、GL、LR、SGS、IEI
Model Number: 1/2" TO 28 "
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Negotiation
Packaging Details: Plywood Cases or Pallets
Delivery Time: 7-15 work days
Payment Terms: L/C, D/P, T/T
Supply Ability: 100000Tons per year
  • Detail Information
  • Product Description

Detail Information

Place Of Origin :: CHINA Payment Terms :: T/T Or Western Union Or LC
Product Name :: Equal Diameter Reducing Tee Certification :: ISO, API, CE
Supply Ability :: 10000 PC Per Month Packaging Details :: Regular Shipping Packaging Or Depends On Customer's Requirement
Connection:: Soldering Lateral:: 90° Tee
High Light:

astm a234 pipe connector t

,

p91 pipe connector t

,

alloy seamless t pipe connector

Product Description

Astm A234 Pipe Connector T P91 P22 A213 12cr1movg Alloy Seamless


Hebei Hongcheng Group Co., Ltd. is a global manufacturer, stocker and exporter of Standard ASME B16.9 Stainless Steel Fitting Tees, we also manufacture ASME/ANSI B16.9 Fitting Tees, ASTM A403 SS ASME B16.9 Fitting Tees , Monel Buttweld ANSI B16.9 Fitting Tee, ASME B16.9 Butt Welding Fitting Tee, 304 SS ASME B16.9 Fitting Tee, Alloy Steel ASME B16.9 Fitting Tee, ANSI B16.9 Butt Fitting Tee, Available in all sizes.



Stainless Steel SCH20 ASME B16.9  Pipe Fitting Tee 0



Chemical Composition:

Chemical Composition of ASTM A234
Element WP5 WP9 WP11 WP91
C Max 0.15 Max .15 0.05 - 0.15 0.08 - 0.12
Mn 0.30 - 0.60 0.30 - 0.60 0.30 - 0.60 0.30 - 0.60
P Max 0.040 Max 0.030 Max 0.030 Max 0.020
S Max 0.030 Max 0.030 Max 0.030 Max 0.010
Si Max 0.50 0.25 - 1.00 0.50 - 1.00 0.20 - 0.50
Ni - - - Max 0.40
Cr 4.0 - 6.0 8.0 - 10.0 1.00 - 1.50 8.0 - 9.5
Mo 0.44 - 0.65 0.90 - 1.10 0.44 - 0.65 0.85 - 1.05
Cu - - - -
Cb - - - 0.060 - 0.10
V - - - 0.18 - 0.25



Mechanical Property:

ASTM A234/A234M

Tensile strength, min



Yield Strength, min Elongation,%, min
Grade Ksi Mpa Ksi Mpa Longitudinal Transverse
WP5 60-85 415 - 585 30 205 22 14
WP9 60-85 415 - 585 30 205 22 14
WP11 60 - 85 415 - 585 40 275 22 14
WP91 85 - 110 585 - 760 60 415 20 -

Astm A234 Pipe Connector T P91 P22 A213 12cr1movg Alloy Seamless 1



Alloy Steel

A234:

WP1, WP12, WP11, WP22, WP5, WP9, WP91

1.5423(16Mo5)

1.7335(13CMo44)/13CrMo4-5

1.7380(10CrMo9-10)

1.7362(12CrMo195)

1.4903/X10CrMoVNb9-1

Carbon Steel

A234:

WPA, WPB, WPC

1.0305 (St35.8) /P235GH(1.0345)

1.0405(St45.8) /P265GH(1.0425)

1.0482(19Mn5)

Low-temperature Steel

A420:

WPL3, WPL6, WPL9

1.5837/1.5637(10Ni14)/12Ni4

1.0488(TSTE285), TSTE355(1.0566)

Line Steel

A860:

WPHY42, WPHY46, WPHY52, WPHY60, WPHY65, WPHY70

1.0457(StE240.7)

1.0484(StE290.7)/L290NB

1.0582(StE360.7)/L360NB

1.8972(StE415.7)/L415NB

Nonferrous metal: Nickel Alloy

B366:

WPNC(UNS N04400/Monel400)

WPHC22(UNSN06022/Hastelloy C22)

WPNC1(UNS N06600/Inconel 600)

WPNCMC(UNS N06625/Inconel 625)

WP20CB(UNS N08020/Alloy 20))

WPNIC(UNS N08800/Incoloy 800)

WPNIC10(UNS N08810/Incoloy 800H)

WPNIC11(UNS N08811/Incoloy 800HT)

WPNICMC(UNS N08825/Incoloy 825)

WPHC276(UNS N10276/Hastelloy C276)

WPHB-2(UNS N10665/Hastelloy B2)


Nonferrous metal: Aluminum Alloy , Titanium Alloy

B361:

WP3003(UNS A93003)

WP6061(UNS A96061)

B363:

WPT1, WPT2, WPT3, WPT7, WPT9, WPT11





Astm A234 Pipe Connector T P91 P22 A213 12cr1movg Alloy Seamless 2

Astm A234 Pipe Connector T P91 P22 A213 12cr1movg Alloy Seamless 3





DIAMENSION OF ASTM B366 GRADE WPNCMC FITTINGS~

Nominal Pipe Size All Fittings All Fittings All Fittings Elbows/ Tees 180° Return Bends 180° Return Bends 180 Deg Return Bends Reducers Caps
NPS O.D. at Bevel (1), (2)

I.D. at End

(1), (3), (4)

Wall Thickness (3) Centre-to-End Dimension A,B,C,M Centre-to-Centre O Back-to-Face K Alignment of Ends U Overall Length H Overall Length E
½ to 2½

0.06

-0.03

0.03 Not less than 87.5% of nominal thickness 0.06 0.25 0.25 0.03 0.06 0.12
3 to 3 ½ 0.06 0.06 Not less than 87.5% of nominal thickness 0.06 0.25 0.25 0.03 0.06 0.12
4 0.06 0.06 Not less than 87.5% of nominal thickness 0.06 0.25 0.25 0.03 0.06 0.12
5 to 8

0.09

-0.06

0.06 Not less than 87.5% of nominal thickness 0.06 0.25 0.25 0.03 0.06 0.25
10 to 18

0.16

-0.12

0.12 Not less than 87.5% of nominal thickness 0.09 0.38 0.25 0.06 0.09 0.25
20 to 24

0.25

-0.19

0.19 Not less than 87.5% of nominal thickness 0.09 0.38 0.25 0.06 0.09 0.25
26 to 30

0.25

-0.19

0.19 Not less than 87.5% of nominal thickness 0.12 0.19 0.38
32 to 48

0.25

-0.19

0.19 Not less than 87.5% of nominal thickness 0.19 0.19 0.38

Astm A234 Pipe Connector T P91 P22 A213 12cr1movg Alloy Seamless 4

Astm A234 Pipe Connector T P91 P22 A213 12cr1movg Alloy Seamless 5

FAQ:



  1. Are you a factory or trading company?

  We are a factory.we also have cooperated factory doing other steel business.

  2. How can I get a quotation from you ?

  You can leave us message, and we will reply every message in time. Or we may talk on line by Trademanager.

  And you can also find our contact information on contact page.

  3.Can I get samples before order ?

  Yes, of course. Usually our samples are free. we can produce by your samples or technical drawings.

  4. what is your delivery time ?

  The time of delivery is usually around 20 days(1*20FT as usual).

  We can send out in 2 days, if it has stock.

  5.What is your payment terms?

  Our usual payment term is 30% deposite, and rest against B/L. L/C is also acceptatble.EXW,FOB,CFR,CIF,DDU.

  6.How does your factory do regarding quality control?

  Quality is priority. Our factory has gained ISO9001 authentication. We guarantee the goods out from our factory 100% qualified.

  And Each Process, we have very strict operation and arrange 2 techinians to inspect. After the products are finished,

  we will make the last test to pick up the unqualified products
