Product Details:
|
|
Place of Origin: | China |
---|---|
Brand Name: | hongcheng |
Certification: | PED、ABS、BV、DNV、GL、LR、SGS、IEI |
Model Number: | 1/2" TO 24 " |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 1PCS |
Price: | 10-50 pieces US $86 / Piece;>50 pieces US $ 74/ Piece |
Packaging Details: | Standard export seaworthy package,or as required |
Delivery Time: | 7-15 work days |
Payment Terms: | L/C, D/P, T/T |
Supply Ability: | 2 Million Ton/Year |
Detail Information |
|||
Size Range: | From ½” Up To 24” | Certification:: | PED .TUV. ISO |
---|---|---|---|
Pressure Rating: | 2000LB/3000LB/6000LB | Download: | Also Can Supply IBR Fittings And Specialized NACE & HIC Fittings.ement |
Material :: | Carbon Steel/ Staniless Steel /Alloy Steel | Painting: | Anti-rust Painting/ Zinc Coated/ Upon Requirement |
High Light: | 90 Degree Forged Steel Pipe Fittings,A182 Forged Steel Pipe Fittings Npt,F11 Forged Steel Elbow 90 Degree |
Product Description
High-pressure pipe fittings forged steel socket welding, butt welding, threaded pipe fittings,
Specifications: Caliber DN6 (1/8")—DN150 (6")
Type: various grades of forgings, products: socket welding union, 90 degree socket welding elbow, 45 degree socket welding elbow, socket welding equal diameter tee, socket reducing tee, socket welding live Joints, socket welded pipe caps, socket welded pipe clamps, socket welded reducing joints, socket welded pipe tables, double socket pipe clamps, single socket pipe clamps, socket welded pipe clamps, socket threaded elbows, forging Threaded button elbow, forged elbow, forged socket elbow, forged socket tees, forged socket reducing tees, forged unions, forged high pressure unions, forged threaded unions , Forged stainless steel union, female thread union, female thread union, forged thread union, cross, pipe cap, plug, pipe clamp, inner wire, outer wire, concentric, eccentric size head, single and double Socket pipe stand, union, etc.
Standard size: | National standard (drawing processing) |
Production standards: | ASME, B16.11, MSSSP75, JIS2316, GB/14383, GB/T14626, SH3410, HG/T21634, GB/T3287-2000, etc. |
Material: | 20#, 201, 304, 321SS, 316SS, etc. |
Pressure rating: | 16-42.0Mpa, 1500LB-9000LB, 3000LB, 6000LB |
Main thread: | BSP, G, ZG, NPT, PT, NPTF, NPTM, etc. |
Joint temperature: | -30℃-440℃, -75℃-330℃, 540℃, 570℃, etc. |
Applicable medium: | water, oil, gas, and other corrosive media |
This product is widely used in industrial automatic control pipelines, petroleum, chemical industry, medicine, boilers, electric power, machinery, pipelines, and metallurgy.
(Common specifications are available in stock, and can be processed and produced according to samples, drawings and the requirements for use of the product)
Note: The unit price of the product is for reference only, and the exact price needs to provide detailed product parameters.
Welcome to inquire.
